R&S ZVB - Page 1091

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 1076
TRACe[:DATA][:RESPonse][:ALL]? CH1DATA | CH2DATA | CH3DATA | CH4DATA |
CH1MEM | CH2MEM | CH3MEM | CH4MEM | MDATA1 | MDATA2 | MDATA3 |
MDATA4 | MDATA5 | MDATA6 | MDATA7 | MDATA8
[Deprecated command]
Returns the response values of the active data trace or memory trace (see trace names).
To read the response values of an arbitrary data or memory trace, use CALCulate<Chn>:DATA? To
read the response values of a trace acquired in single sweep mode (INITiate<Ch>:CONTinuous
OFF), use CALCulate<Chn>:DATA:NSWeep:FIRSt?
<Response>
Response data of the selected trace, see list of trace names.
Range [def.
unit]
The data is transferred in the data format defined via FORMat[:DATA] and
FORMat:DEXPort:SOURce. The unit is the default unit of the measured
parameter; see CALCulate<Ch>:PARameter:SDEFine.
*RST value
–
SCPI,
Command
Types
Device-specific, query only
Example:
SWE:POIN 20
Create a trace with 20 sweep points, making the created trace the active trace of
channel 1 (omitted optional mnemonic SENSe1).
CALC:FORM MLIN; :FORM ASCII; FORM:DEXP:SOUR FDAT
Select the trace data format: linear magnitude values, ASCII format and formatted
trace data (1 value per sweep point).
TRAC? CH1DATA
Query the 20 response values of the created trace according to the previous
format settings.
TRACe[:DATA]:STIMulus[:ALL]? CH1DATA | CH2DATA | CH3DATA | CH4DATA |
CH1MEM | CH2MEM | CH3MEM | CH4MEM | MDATA1 | MDATA2 | MDATA3 |
MDATA4 | MDATA5 | MDATA6 | MDATA7 | MDATA8
[Deprecated command]
Returns the stimulus values of the active data trace or memory trace (see trace names).
To read the stimulus values of an arbitrary data or memory trace, use
CALCulate<Chn>:DATA:STIMulus?
<Response>
Response data of the selected trace, see list of trace names.
Range [def. unit]
The data is transferred in the data format defined via FORMat[:DATA]. The
numeric values are expressed in the default unit of the stimulus variable. [Hz,
dBm or s, depending on the sweep type]
*RST value
–
