ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 615
Types
Example:
Analogous to CALCulate<Chn>:DATA:ALL?; see CALCulate<Chn>:DATA.
CALCulate<Ch>:DATA:SGRoup? FDATa | SDATa | MDATa
Reads the current response values of all S-parameters associated to a group of logical ports (S-parameter
group). The S-parameter group must be created before using
CALCulate<Ch>:PARameter:DEFine:SGRoup.
<Ch>
Channel number of the previously defined S-parameter group.
Parameters
Output format for the S-parameter data, see CALCulate<Chn>:DATA.
*RST value
–
SCPI, Command
Types
Device-specific, query only. The order of the returned S-parameters within the
S-parameter group is fixed; see example.
Example:
See CALCulate<Ch>:PARameter:DEFine:SGRoup
CALCulate<Chn>:DATA:NSWeep:COUNt?
Reads the number of completed sweeps in single sweep mode (INITiate<Ch>:CONTinuous OFF).
The trace can be any of the traces acquired during the single sweep cycle.
<Chn>
Channel number used to identify the active trace.
Response
Number of last completed sweep.
Range [def. unit]
1 to sweep count defined via [SENSe<Ch>:]SWEep:COUNt
[–]
*RST value
–
SCPI, Command Types
Device-specific, query only
Example (see also Sweep
History):
See CALCulate<Chn>:DATA:NSWeep:FIRSt?
CALCulate<Chn>:DATA:NSWeep:FIRSt? SDATa, <Forward_Count>[,
<Forward_Count_End>]
Reads the response values of a trace or a consecutive group of traces acquired in single sweep mode
(INITiate<Ch>:CONTinuous OFF). The trace can be any of the traces acquired during the single
sweep cycle.
<Chn>
Channel number used to identify the active trace.
SDATa
Read unformatted sweep data (fixed parameter): Returns the real and
imaginary part of each measurement point (2 values per trace point
irrespective of the selected trace format). Wave quantities are returned
as voltages.
