R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 614
system error correction (TOSM, TOM, TRL ...) is active in this channel, the command reads the full nxn S-
matrix of the calibrated ports (there is no need to create or display the S-parameter traces). Use
CALCulate<Ch>:DATA:CALL:CATalog? to query the available traces.
<Ch>
Channel number.
Parameters
SDATA: see CALCulate<Chn>:DATA.
Other output formats are not supported.
*RST value
–
SCPI,
Command
Types
Device-specific, query only.
Example:
Suppose that a TOSM calibration for ports 1 and 3 is active in channel no. 1.
:CALCulate:DATA:CALL:CATalog?
Query the traces available for CALCulate<Ch>:DATA:CALL?. The response is
'S11,S13,S31,S33'
CALCulate:DATA:CALL? SDATa
Return the complex response values of all traces. The traces in the catalog list are
read one after another: The response array contains n (number of points) pairs of
real and imaginary values for S
11
, followed by n pairs of values for S
13
, S
31
, and S
33
.
CALCulate<Ch>:DATA:CALL:CATalog?
Returns all traces which are available for CALCulate<Ch>:DATA:CALL? in channel no. <Ch>.
<Ch>
Channel number.
Response
String parameters with all S-parameter traces in the current channel or in the
active system error correction; see example.
*RST value
–
SCPI, Command
Types
Device-specific, query only.
Example:
See CALCulate:DATA:CALL?
CALCulate<Chn>:DATA:DALL? FDATa | SDATa | MDATa
Reads the current response values of all data traces of the current test setup. Use
CALCulate<Ch>:DATA:ALL? to query data traces and memory traces.
<Chn>
Channel number used to identify the active trace. This suffix is ignored, the
commands returns all data traces.
Parameters
Output format for the S-parameter data, see CALCulate<Chn>:DATA.
*RST value
–
SCPI, Command
Device-specific, query only.
