R&S ZVB - Page 628

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 613
Error Term
Description
Receive Ports (S-parameter)
SCORr1, ... SCORr12
2-port error terms; see [SENSe<Ch>:]CORRection:DATA ( ).
1 and 2 (S11, S12, S21, S22)
SCORr13
Directivity
3 (S33)
SCORr14
Source match
3 (S33)
SCORr15
Reflection tracking
3 (S33)
SCORr16
Isolation
3 (S31)
SCORr17
Load match
3 (S31)
SCORr18
Transmission tracking
3 (S13)
SCORr19
Isolation
1 (S13)
SCORr20
Load match
1 (S13)
SCORr21
Transmission tracking
1 (S13)
SCORr22
Isolation
3 (S32)
SCORr23
Load match
3 (S32)
SCORr24
Transmission tracking
3 (S32)
SCORr25
Isolation
2 (S23)
SCORr26
Load match
2 (S23)
SCORr27
Transmission tracking
2 (S23)
The error terms are channel-specific; they apply to the active calibration of channel no. <Chn> or to
the factory calibration (if no channel calibration is active). For the factory calibration, the query form is
allowed only (no change of factory calibration data).
Use the generalized command [SENSe<Ch>:]CORRection:CDATa to read or write error terms for
arbitrary analyzer ports. For a programming example refer to Saving and Recalling Error Terms.
CALCulate<Chn>:DATA:ALL? FDATa | SDATa | MDATa
Reads the current response values of all data and memory traces of the current test setup.
<Chn>
Channel number used to identify the active trace. This suffix is ignored, the
commands returns all traces.
Parameters
Output format for the S-parameter data, see CALCulate<Chn>:DATA.
*RST value
–
SCPI, Command
Types
Device-specific, query only.
Example:
See CALCulate<Chn>:DATA
CALCulate<Ch>:DATA:CALL? SDATa
Reads the current response values of all S-parameter data traces in channel no. <Ch>. If a full n-port
