ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 617
Activate single sweep mode and start a single sweep sequence in channel
no. 1. Wait until the single sweep sequence is complete.
CALC:DATA:NSW? SDAT,3
Query the results of the 8
th
sweep.
CALCulate<Chn>:DATA:STIMulus?
Reads the stimulus values of the active data or memory trace.
<Chn>
Channel number used to identify the active trace.
Parameters
–
Range [def. unit]
The data is transferred in the data format defined via FORMat[:DATA]. The unit
is the default unit of the sweep variable (Hz or dBm or s).
*RST value
–
SCPI, Command
Types
Device-specific, query only
Example:
See CALCulate<Chn>:DATA?
CALCulate<Chn>:DLINe...
This subsystem controls the horizontal line used to mark and retrieve response values (display line).
CALCulate<Chn>:DLINe <numeric_value>
Defines the position (response value) of the horizontal line.
<Chn>
Channel number used to identify the active trace. If unspecified the numeric
suffix is set to 1.
Parameters
See list of parameters below.
Range [def. unit]
–200 dB to +200 dB [dB]
*RST value
0 dB
SCPI, Command
Types
Device-specific, command or query.
Example:
*RST; :CALC:DLIN 10
Define the position of the horizontal line in the default dB Mag diagram at
+10 dBm.
CALC:DLIN:STAT ON
Display the defined horizontal line.
