R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Annexes
Configuration Files for External Devices
Operating Manual 1145.1084.12 – 30 1162
Parameter
Status
Description
values according to C++ printf rules.
Examples: :SOUR:FREQ %lf Hz
:SOUR:FREQ %5e
GENERATORLEVEL
mandatory
SCPI command to set the generator power [dBm].
Format: <Command> <Power format>
Command: SCPI command to set the power
Power format: Defines the power format for double
values according to the C++ printf rules
Example: :POW %lf DBM
GENERATORRFOFF
mandatory
SCPI command to turn RF output OFF
Example: :OUTP:STAT OFF
GENERATORRFON
mandatory
SCPI command to turn RF output ON
Example: :OUTP:STAT ON
GENERATORREFEXT
optional
SCPI command to set reference oscillator to EXT.
Optional parameter, as not every generator supports this
command.
Example:
:ROSC:EXT:FREQ 10e6;:ROSC:SOUR EXT
GENERATORREFINTERN
optional
SCPI command to set reference oscillator to INT
Optional parameter, as not every generator supports this
command.
Example:
:ROSC:SOUR INT
GENERATORIECAVAIL
mandatory
Qualifies whether list mode is available (i.e. whether the
generator supports hardware handshake)?
IEC = List mode not supported
TTL = List mode supported
In list mode the generator steps through a predefined list of
frequencies or signal power levels via hardware handshake.
This is supported with Rohde & Schwarz generators only.
GENERATORNOFLISTS
Mandatory if
GENERATORIECAVAIL =
TTL, else unnecessary
Maximum number of lists for generator list mode [int]
GENERATORNOFPOINTSPERLIST
Mandatory if
GENERATORIECAVAIL =
TTL, else unnecessary
Maximum number of points per list for generator list mode
[int]
GENERATORLISTMAX
Mandatory if
GENERATORIECAVAIL =
TTL, else unnecessary
Maximum number of points for all lists together [int]
GENERATOR_TRIGPULSE_WIDTH
Mandatory if
GENERATORIECAVAIL =
TTL, else unnecessary
Trigger pulse length [sec]
GENERATORREADYINVALIDTIME
Mandatory if
GENERATORIECAVAIL =
TTL, else unnecessary
Settling time after blank-signal [sec]
if blank-signal is ready and GENERATORREADYINVALIDTIME
elapsed -> the external generator should be ready and we
can start the measurement.
GENERATORINITLIST
Mandatory if
GENERATORIECAVAIL =
TTL, else unnecessary
SCPI command to activate and initialize the list mode.
The command has to:
- Select list mode
