R&S ZVB - Page 751

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 736
assigned to diagram areas (DISPlay:WINDow<Wnd>:TRACe<WndTr>:FEED <Trace_Name>). While
this assignment is valid, the trace is identified by the numeric suffix <WndTr> and the trace name is not
needed.
DISPlay:ANNotation:FREQuency[:STATe] <Boolean>
Shows or hides all frequency stimulus values in the diagrams.
<Boolean>
ON | OFF - Show or hide stimulus values.
*RST value
ON
SCPI, Command
Types
Confirmed, command or query
Example:
*RST; :DISP:ANN:FREQ OFF
Create diagram area no. 1 (with default trace) and hide the frequency
stimulus values.
DISPlay:ANNotation:CHANnel[:STATe] <Boolean>
Shows or hides the channel list below the diagrams.
<Boolean>
ON | OFF - Show or hide channel list.
*RST value
ON
SCPI, Command Types
Device-specific, command or query
Example:
*RST; :DISP:ANN:CHAN OFF
Create diagram area no. 1 (with default trace) and hide the channel list.
DISPlay:CMAP<Element>:MARKer[:STATe] <Boolean>
Displays all markers with the same color or display each marker with the color of the associated trace. The
colors of all display elements are defined via DISPlay:CMAP<Element>:RGB <red>, <green>,
<blue>,....
<Element>
Numeric suffix, not used in this command. Implemented for compatibility with
DISPlay:CMAP<Element>:RGB.
<Boolean>
ON – All markers have the same color, to be defined via DISPlay:CMAP6:RGB
<red>, <green>, <blue>. The marker color is independent of the trace
colors.
OFF - Each marker has the color of the associated trace.
*RST value
*RST does not affect the color settings; see also description of the Preset
command.
SCPI,
Command
Device-specific, command or query
