R&S ZVB - Page 812

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 797
<channel no.> |
ALL
Channel number in the active setup.
ALL – A separate file is created for each channel in the active setup.
'<file_name>'
String parameter to specify the name and directory of the created trace file.
Several file formats for trace files are supported. The file extensions *.s<n>p,
*.csv, and *.dat for Touchstone, ASCII, and Matlab files are mandatory.
To generate a multiport Touchstone file *.s2p, *.s3p..., the channel must contain
traces for the full set of S-parameters.
If no path is specified the analyzer uses the C:\Program
Files\Rohde&Schwarz\Network Analyzer\Traces directory.
Optional
parameters
UNFormatted – Unformatted data export specified by the second optional
parameter
FORMatted – Formatted data export (for *.csv and *.dat files only)
If the first optional parameter is omitted, the command stores unformatted data.
COMPlex – Complex values (real and imaginary part)
LINPhase – Linear magnitude and phase
LOGPhase – dB-magnitude and phase
If the second optional parameter is omitted, the command stores complex data.
POINt – Decimal separator: point
COMMa – Decimal separator: comma
If the third optional parameter is omitted, points are used.
SEMicolon – Field separator: semicolon
COMMa – Field separator: comma
TABulator – Field separator: tabulator
SPACe – Field separator: space
If the third optional parameter is omitted, semicolons are used.
*RST value
– (the default export format is UNFormatted)
SCPI,
Command
Types
Confirmed, no query.
Example:
*RST; :CONF:TRAC:NAME?
Reset the instrument, creating a default channel no 1 and a default trace Trc1.
CALC:PAR:DEF:SGR 1,2
Create four traces to measure the two-port S-parameters S
11
, S
12
, S
21
, S
22
. The
traces are not displayed.
MMEM:STOR:TRAC:CHAN 1, 'C:\Program
Files\Rohde&Schwarz\Network Analyzer\Traces\Chn1.csv'
Store all trace data of channel 1 to a trace file.
MMEM:STOR:TRAC:CHAN 1, 'C:\Program
Files\Rohde&Schwarz\Network Analyzer\Traces\Chn1.s2p'
Store the four S-parameter traces to a two-port Touchstone
file. The Touchstone file will not contain the default trace
Trc1.
