ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 810
SCPI, Command
Types
Device-specific, with query.
Example:
*RST; :ROUT:CFIL?
Reset the analyzer and query the default configuration state. The response is 1
(default settings are used).
ROUT5:PORTS A, 2
Change the signal routing for channel no. 5 and port group A.
ROUT:CFIL?
Query the default configuration state again. The response is 0 (default settings
are no longer used).
ROUTe<Ch>:PORTs <port group>, <port no>{, <port group>, <port no>}
Configures the internal signal paths of the switch matrix/multiport test set for channel no. <Ch>.
<Ch>
Channel number.
<port group>
Group of "output" ports of the test set.
Range [def.
unit]
A | B | C | D
*RST value
See example below
<port no.>
"Output" port number
Range [def.
unit]
0 – retain the existing port configuration when channel <Ch> is measured.
1 | 2 | 3 | 4 – use port no. 1, 2, 3, 4
*RST value
0 (see example below)
SCPI,
Command
Types
Device-specific, command or query
Example:
*RST; :ROUT1:PORT?
Query the default port configuration of the switch matrix/multiport test set. The
analyzer returns A, 0, B, 0, C, 0, D, 0. Channel 1 does not change the
previous port configuration.
CONF:CHAN2 ON; CHAN3 ON; CHAN4 ON
Create channels no. 2, 3, 4.
ROUT1:PORT A, 1, B, 1, C, 1, D, 1; :ROUT2:PORT A, 2, B, 3, C, 4, D, 4
Use the "output" ports no. A1, B1, C1, D1 for channel 1, A2, B3, C4, D4 for
channel 2.
ROUT3:PORT A, 4, D, 3
Use the "output" port no. A4 and D3 for channel 3, do not change port B and C
when measuring channel 3.
ROUT4:PORT A, 4, B, 0, C, 0, D, 3
Select the port configuration for channel 4 to be identical with channel 3.
