R&S ZVB - Page 929

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 914
Output: A<Pt
out
>/B<Pt
in
>
POWer:A<Pt
out
>
Wave quantity with stimulus port number of the analyzer, e.g. A1.
POWer:B<Pt
in
>
Wave quantity with receive port number of the analyzer, e.g. B2.
POWer:Z<Pt
out
><Pt
in
>
Matched-circuit impedance (converted Z-parameter) with output and input port
number of the DUT, e.g. Z11, Z21.
POWer:Y<Pt
out
><Pt
in
>
Matched-circuit admittance (converted Y-parameter) with output and input port
number of the DUT, e.g. Y11, Y21.
POWer:KFACtor
POWer:MUFactor<1|2>
Stability factor K
Stability factors μ1 or μ2
PAE<Pt
out
><Pt
in
>
Power Added Efficiency (PAE) with output and input port number of the DUT,
e.g. PAE21 (output variable for query only)
VOLTage[:DC] DCIN1 | DCIN2
Output: DC 1 V, DC 10 V
DC Input 1 (DC –1 V...+1 V) or DC Input 2 (DC –10 V...+10 V)
Note: The mnemonics POWer: and VOLTage: are not used in output strings.
[SENSe<Ch>:]LO...
This subsystem controls the Local Oscillator (LO) amplifiers for the reference and measurement channels.
[SENSe<Ch>:]LOMeasure<Pt>[:STATe] <Boolean>
Switches the Local Oscillator amplifier for the measurement channel b on or off.
<Ch>
Channel number. If unspecified the numeric suffix is set to 1.
<Pt>
Test port number of the analyzer.
<Boolean>
ON | OFF – Switches the LO oscillator on or off.
*RST value
ON
SCPI, Command
Types
Device-specific, command or query
Example:
LOM1 OFF; LOR1 OFF
Switch the local oscillators for the measurement channel b and the reference
channel a at port no. 1 off.
[SENSe<Ch>:]LOReference<Pt>[:STATe] <Boolean>
Switches the Local Oscillator amplifier for the reference channel a on or off.
<Ch>
Channel number.
<Pt>
Test port number of the analyzer.
<Boolean>
ON | OFF – Switches the LO oscillator on or off.
