Renesas M32R/ECU Series User Manual

5
5-14
INTERRUPT CONTROLLER (ICU)
32180 Group User’s Manual (Rev.1.0)
5.5 Description of Interrupt Operation
Table 5.5.1 Hardware Fixed Priority Levels
Priority Interrupt Request Source ICU Vector Table Address ICU Type of Input Source
High TIN3–6 input interrupt request H'0000 0094 – H'0000 0097 Level-recognized
TIN20–29 input interrupt request H'0000 0098 – H'0000 009B Level-recognized
TIN12–19 input interrupt request H'0000 009C – H'0000 009F Level-recognized
TIN0–2 input interrupt request H'0000 00A0 – H'0000 00A3 Level-recognized
TIN7–11 input interrupt request H'0000 00A4 – H'0000 00A7 Level-recognized
TMS0,1 output interrupt request H'0000 00A8 – H'0000 00AB Level-recognized
TOP8,9 output interrupt request H'0000 00AC – H'0000 00AF Level-recognized
TOP10 output interrupt request H'0000 00B0 – H'0000 00B3 Edge-recognized
TIO4–7 output interrupt request H'0000 00B4 – H'0000 00B7 Level-recognized
TIO8,9 output interrupt request H'0000 00B8 – H'0000 00BB Level-recognized
TOP0–5 output interrupt request H'0000 00BC – H'0000 00BF Level-recognized
TOP6,7 output interrupt request H'0000 00C0 – H'0000 00C3 Level-recognized
TIO0–3 output interrupt request H'0000 00C4 – H'0000 00C7 Level-recognized
DMA0–4 interrupt request H'0000 00C8 – H'0000 00CB Level-recognized
SIO1 receive interrupt request H'0000 00CC – H'0000 00CF Edge-recognized
SIO1 transmit interrupt request H'0000 00D0 – H'0000 00D3 Edge-recognized
SIO0 receive interrupt request H'0000 00D4 – H'0000 00D7 Edge-recognized
SIO0 transmit interrupt request H'0000 00D8 – H'0000 00D8 Edge-recognized
A-D0 conversion interrupt request H'0000 00DC – H'0000 00DF Edge-recognized
TID0 output interrupt request H'0000 00E0 – H'0000 00E3 Edge-recognized
TOU0 output interrupt request H'0000 00E4 – H'0000 00E7 Level-recognized
DMA5–9 interrupt request H'0000 00E8 – H'0000 00EB Level-recognized
SIO2,3 transmit/receive interrupt request H'0000 00EC – H'0000 00EF Level-recognized
RTD interrupt request H'0000 00F0 – H'0000 00F3 Edge-recognized
TID1 output interrupt request H'0000 00F4 – H'0000 00F7 Edge-recognized
TOU1,2 output interrupt request H'0000 00F8 – H'0000 00FB Level-recognized
SIO4,5 transmit/receive interrupt request H'0000 00FC – H'0000 00FF Level-recognized
A-D1 conversion interrupt request H'0000 0100 – H'0000 0103 Edge-recognized
TID2 output interrupt request H'0000 0104 – H'0000 0107 Edge-recognized
TIN30–33 input interrupt request H'0000 0108 – H'0000 010B Level-recognized
CAN0 transmit/receive & error interrupt H'0000 010C – H'0000 010F Level-recognized
request
CAN1 transmit/receive & error interrupt H'0000 0110 – H'0000 0113 Level-recognized
Low request
Table 5.5.2 ILEVEL Settings and Accepted IMASK Values
ILEVEL values set IMASK values at which interrupts are accepted
0 (ILEVEL = "000") Accepted when IMASK is 1–7
1 (ILEVEL = "001") Accepted when IMASK is 2–7
2 (ILEVEL = "010") Accepted when IMASK is 3–7
3 (ILEVEL = "011") Accepted when IMASK is 4–7
4 (ILEVEL = "100") Accepted when IMASK is 5–7
5 (ILEVEL = "101") Accepted when IMASK is 6–7
6 (ILEVEL = "110") Accepted when IMASK is 7
7 (ILEVEL = "111") Not accepted (interrupts disabled)
