MULTIJUNCTION TIMERS
10.5 TMS (Input-Related 16-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
10.5.4 TMS Control Registers
The TMS control registers are used to select TMS0/1 input events and count clock sources, as well as control
count enable. Following two TMS control registers are included:
• TMS0 Control Register (TMS0CR)
• TMS1 Control Register (TMS1CR)
TMS0 Control Register (TMS0CR)
<Address: H
’0080 03CA>123456b7b0
TMS0SS0 TMS0SS1 TMS0SS2 TMS0SS3 TMS0CKS TMS0CEN
000000 0
<After reset: H’00>
b Bit Name Function R W
0 TMS0SS0 0: External input TIN15 R W
TMS0 measure 0 source select bit 1: Input event bus 0
1 TMS0SS1 0: External input TIN14 R W
TMS0 measure 1 source select bit 1: Input event bus 1
2 TMS0SS2 0: External input TIN13 R W
TMS0 measure 2 source select bit 1: Input event bus 2
3 TMS0SS3 0: External input TIN12 R W
TMS0 measure 3 source select bit 1: Input event bus 3
4, 5 TMS0CKS 00: External input TCLK3 R W
TMS0 clock source select bit 01: Clock bus 0
10: Clock bus 1
11: Clock bus 3
6 No function assigned. Fix to "0". 00
7 TMS0CEN 0: Stop count R W
TMS0 count enable bit 1: Start count
TMS1 Control Register (TMS1CR)
<Address: H
’0080 03CB>9 1011121314b15b8
TMS1SS0 TMS1SS1 TMS1SS2 TMS1SS3 TMS1CKS TMS1CEN
0000 0 0
<After reset: H’00>
b Bit Name Function R W
8 TMS1SS0 0: External input TIN19 R W
TMS1 measure 0 source select bit 1: Input event bus 0
9 TMS1SS1 0: External input TIN18 R W
TMS1 measure 1 source select bit 1: Input event bus 1
10 TMS1SS2 0: External input TIN17 R W
TMS1 measure 2 source select bit 1: Input event bus 2
11 TMS1SS3 0: External input TIN16 R W
TMS1 measure 3 source select bit 1: Input event bus 3
12 No function assigned. Fix to "0". 00
13 TMS1CKS 0: Clock bus 0 R W
TMS1 clock source select bit 1: Clock bus 3
14 No function assigned. Fix to "0". 00
15 TMS1CEN 0: Stop count R W
TMS1 count enable bit 1: Start count
