10
10-140
MULTIJUNCTION TIMERS
10.7 TID (Input-Related 16-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
10.7.2 TID Related Register Map
Shown below is a TID related register map.
TID Related Register Map
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 078C TID0 Counter 10-144
(TID0CT)
H'0080 078E TID0 Reload Register 10-144
(TID0RL)
H'0080 07D0 Prescaler Register 3 TID0 Control & Prescaler 3 Enable Register 10-12
(PRS3) (TID0PRS3EN) 10-141
H'0080 0B8C TID1 Counter 10-144
(TID1CT)
H'0080 0B8E TID1 Reload Register 10-144
(TID1RL)
H'0080 0BD0 Prescaler Register 4 TID1 Control & Prescaler 4 Enable Register 10-12
(PRS4) (TID1PRS4EN) 10-142
H'0080 0C8C TID2 Counter 10-144
(TID2CT)
H'0080 0C8E TID2 Reload Register 10-144
(TID2RL)
H'0080 0CD0 Prescaler Register 5 TID2 Control & Prescaler 5 Enable Register 10-12
(PRS5) (TID2PRS5EN) 10-143
|
|
|
|
|
To Next Page
