10
10-169
MULTIJUNCTION TIMERS
10.8 TOU (Output-Related 24-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
10.8.8 TOU Count Enable Registers
TOU0 Count Enable Register (TOU0CEN)
<Address: H
’0080 07DF>TOU1 Count Enable Register (TOU1CEN)
<Address: H'0080 0BDF>
TOU2 Count Enable Register (TOU2CEN)
<Address: H'0080 0CDF>
9 1011121314b15b8
TOUn
0CEN
TOUn
1CEN
TOUn
2CEN
TOUn
3CEN
TOUn
4CEN
TOUn
5CEN
TOUn
6CEN
TOUn
7CEN
00000000
<After reset: H’00>
b Bit Name Function R W
8 TOUn0CEN 0: Stop count R W
TOUn_0 count enable bit 1: Enable count
9 TOUn1CEN
TOUn_1 count enable bit
10 TOUn2CEN
TOUn_2 count enable bit
11 TOUn3CEN
TOUn_3 count enable bit
12 TOUn4CEN
TOUn_4 count enable bit
13 TOUn5CEN
TOUn_5 count enable bit
14 TOUn6CEN
TOUn_6 count enable bit
15 TOUn7CEN
TOUn_7 count enable bit
The TOU count enable registers control operation of the TOU counters. To enable any TOU counter in software,
enable its corresponding enable protect bit for rewrite and set the count enable bit by writing "1". To stop any
TOU counter, enable its corresponding enable protect bit for rewrite and reset the count enable bit by writing "0".
In single-shot output, single-shot PWM output or delayed single-shot output mode, when the counter stops due
to occurrence of an underflow, the count enable bit is automatically reset to "0". Therefore, the TOU count
enable register when accessed for read serves as a status register indicating whether the counter is operating or
idle.
