ELECTRICAL CHARACTERISTICS
32180 Group User's Manual (Rev.1.0)
Symbol Parameter Test Condition Rated Value Unit
MIN TYP MAX
– Resolution VREF=VCCE=AVCC 10 bits
– Absolute Without sample- Slow mode Normal speed ±2 LSB
Accuracy and-hold or Double speed ±2
(Note 1) during normal Fast mode Normal speed ±3
sample-and-hold Double speed ±3
During fast Slow mode Normal speed ±3
sample-and Double speed ±3
-hold Fast mode Normal speed ±3
Double speed ±8
TCONV Conversion Without sample- Slow mode Normal speed 14.95 µs
Time and-hold or Double speed 8.65
during normal Fast mode Normal speed 6.55
sample-and-hold Double speed 4.45
During fast Slow mode Normal speed 9.55
sample-and Double speed 5.05
-hold Fast mode Normal speed 4.75
Double speed 2.65
IIAN Analog Input Leakage Current (Note 2) AVSS≤ANi≤AVCC -5 5 µA
Note 1: Absolute accuracy refers to the accuracy of output code relative to the analog input including all error sources
(including quantization error) in an A-D converter, and is calculated using the equation below.
Absolute accuracy = output code – (analog input voltage Ani / 1 LSB)
When AVCC = AVREF = 5.12 V, 1 LSB = 5 mV.
Note 2: This refers to the input leakage current on ANi while the A-D converter remains idle.
21.2.3 A-D Conversion Characteristics (when VCCE = 5 V, f(XIN) = 10 MHz)
A-D Conversion Characteristics (Referenced to VCCE, OSC-VCC, VCC-BUS, VDDE = 5.12 V, Ta = –40°C to
85°C Unless Otherwise Noted)
21.2 Electrical Characteristics when VCCE = 5 V, f(XIN) = 10 MHz
