3
3-36
ADDRESS SPACE
32180 Group User’s Manual (Rev.1.0)
3.6 ICU Vector Table
The ICU vector table is used by the internal interrupt controller of the microcomputer. This table has the addresses
shown below, at which the start addresses of interrupt handlers for the interrupt requests from respective internal
peripheral I/Os are set. For details, see Chapter 5, “Interrupt Controller.”
ICU Vector Table Memory Map (1/2)
Address +0 address +1 address
b0 b7 b8 b15
H'0000 0094 TIN3–6 Input Interrupt Handler Start Address (A0–A15)
H'0000 0096 TIN3–6 Input Interrupt Handler Start Address (A16–A31)
H'0000 0098 TIN20–29 Input Interrupt Handler Start Address (A0–A15)
H'0000 009A TIN20–29 Input Interrupt Handler Start Address (A16–A31)
H'0000 009C TIN12–19 Input Interrupt Handler Start Address (A0–A15)
H'0000 009E TIN12–19 Input Interrupt Handler Start Address (A16–A31)
H'0000 00A0 TIN0–2 Input Interrupt Handler Start Address (A0–A15)
H'0000 00A2 TIN0–2 Input Interrupt Handler Start Address (A16–A31)
H'0000 00A4 TIN7–11 Input Interrupt Handler Start Address (A0–A15)
H'0000 00A6 TIN7–11 Input Interrupt Handler Start Address (A16–A31)
H'0000 00A8 TMS0, 1 Output Interrupt Handler Start Address (A0–A15)
H'0000 00AA TMS0, 1 Output Interrupt Handler Start Address (A16–A31)
H'0000 00AC TOP8, 9 Output Interrupt Handler Start Address (A0–A15)
H'0000 00AE TOP8, 9 Output Interrupt Handler Start Address (A16–A31)
H'0000 00B0 TOP10 Output Interrupt Handler Start Address (A0–A15)
H'0000 00B2 TOP10 Output Interrupt Handler Start Address (A16–A31)
H'0000 00B4 TIO4–7 Output Interrupt Handler Start Address (A0–A15)
H'0000 00B6 TIO4–7 Output Interrupt Handler Start Address (A16–A31)
H'0000 00B8 TIO8, 9 Output Interrupt Handler Start Address (A0–A15)
H'0000 00BA TIO8, 9 Output Interrupt Handler Start Address (A16–A31)
H'0000 00BC TOP0–5 Output Interrupt Handler Start Address (A0–A15)
H'0000 00BE TOP0–5 Output Interrupt Handler Start Address (A16–A31)
H'0000 00C0 TOP6, 7 Output Interrupt Handler Start Address (A0–A15)
H'0000 00C2 TOP6, 7 Output Interrupt Handler Start Address (A16–A31)
H'0000 00C4 TIO0–3 Output Interrupt Handler Start Address (A0–A15)
H'0000 00C6 TIO0–3 Output Interrupt Handler Start Address (A16–A31)
H'0000 00C8 DMA0–4 Interrupt Handler Start Address (A0–A15)
H'0000 00CA DMA0–4 Interrupt Handler Start Address (A16–A31)
H'0000 00CC SIO1 Receive Interrupt Handler Start Address (A0–A15)
H'0000 00CE SIO1 Receive Interrupt Handler Start Address (A16–A31)
H'0000 00D0 SIO1 Transmit Interrupt Handler Start Address (A0–A15)
H'0000 00D2 SIO1 Transmit Interrupt Handler Start Address (A16–A31)
H'0000 00D4 SIO0 Receive Interrupt Handler Start Address (A0–A15)
H'0000 00D6 SIO0 Receive Interrupt Handler Start Address (A16–A31)
3.6 ICU Vector Table
To Next Page
