10-111
10
10.4 TIO (Input/Output-Related 16-Bit Timer)
MULTIJUNCTION TIMERS
32180 Group User’s Manual (Rev.1.0)
10.4.7 TIO Reload 1 Registers (TIO0RL1–TIO9RL1)
TIO0 Reload 1 Register (TIO0RL1)
<Address: H
’0080 0304>TIO1 Reload 1 Register (TIO1RL1)
<Address: H
’0080 0314>TIO2 Reload 1 Register (TIO2RL1)
<Address: H
’0080 0324>TIO3 Reload 1 Register (TIO3RL1)
<Address: H
’0080 0334>TIO4 Reload 1 Register (TIO4RL1)
<Address: H
’0080 0344>TIO5 Reload 1 Register (TIO5RL1)
<Address: H
’0080 0354>TIO6 Reload 1 Register (TIO6RL1)
<Address: H
’0080 0364>TIO7 Reload 1 Register (TIO7RL1)
<Address: H
’0080 0374>TIO8 Reload 1 Register (TIO8RL1)
<Address: H
’0080 0384>TIO9 Reload 1 Register (TIO9RL1)
<Address: H
’0080 0394>b01234567891011121314b15
TIO0RL1–TIO9RL1
????????????????
<After reset: Undefined>
b Bit Name Function R W
0–15 TIO0RL1–TIO9RL1 16-bit reload register value R W
Note: • This register must always be accessed in halfwords.
The TIO Reload 1 Registers are used to reload data into the TIO Count Registers (TIO0CT–TIO9CT).
The content of the reload 1 register is loaded into the counter in the following cases:
• When the count value set by the reload 0 register underflowed in PWM output mode
Simply because data is written to the reload 1 register does not mean that the data is loaded into the counter.
The counter is loaded with data in only the above cases.
