Renesas M32R/ECU Series User Manual

10
10-68
MULTIJUNCTION TIMERS
10.3 TOP (Output-Related 16-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
10.3.3 TOP Related Register Map
Shown below is a TOP related register map.
TOP Related Register Map (1/2)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0240 TOP0 Counter 10-75
(TOP0CT)
H'0080 0242 TOP0 Reload Register 10-76
(TOP0RL)
H'0080 0244 (Use inhibited area)
H'0080 0246 TOP0 Correction Register 10-77
(TOP0CC)
(Use inhibited area)
H'0080 0250 TOP1 Counter 10-75
(TOP1CT)
H'0080 0252 TOP1 Reload Register 10-76
(TOP1RL)
H'0080 0254 (Use inhibited area)
H'0080 0256 TOP1 Correction Register 10-77
(TOP1CC)
(Use inhibited area)
H'0080 0260 TOP2 Counter 10-75
(TOP2CT)
H'0080 0262 TOP2 Reload Register 10-76
(TOP2RL)
H'0080 0264 (Use inhibited area)
H'0080 0266 TOP2 Correction Register 10-77
(TOP2CC)
(Use inhibited area)
H'0080 0270 TOP3 Counter 10-75
(TOP3CT)
H'0080 0272 TOP3 Reload Register 10-76
(TOP3RL)
H'0080 0274 (Use inhibited area)
H'0080 0276 TOP3 Correction Register 10-77
(TOP3CC)
(Use inhibited area)
H'0080 0280 TOP4 Counter 10-75
(TOP4CT)
H'0080 0282 TOP4 Reload Register 10-76
(TOP4RL)
H'0080 0284 (Use inhibited area)
H'0080 0286 TOP4 Correction Register 10-77
(TOP4CC)
(Use inhibited area)
H'0080 0290 TOP5 Counter 10-75
(TOP5CT)
H'0080 0292 TOP5 Reload Register 10-76
(TOP5RL)
H'0080 0294 (Use inhibited area)
H'0080 0296 TOP5 Correction Register 10-77
(TOP5CC)
H'0080 0298 (Use inhibited area)
|
|
|
|
|
