11
11-13
A-D Converters
32180 Group User's Manual (Rev.1.0)
11.2 A-D Converter Related Registers
11.2 A-D Converter Related Registers
Shown below is an A-D converter related register map.
A-D Converter Related Register Map (1/3)
Address +0 address +1 address See
b0 b7 b8 b15 pages
H'0080 0080 A-D0 Single Mode Register 0 A-D0 Single Mode Register 1 11-16
(AD0SIM0) (AD0SIM1) 11-18
H'0080 0082 (Use inhibited area)
H'0080 0084 A-D0 Scan Mode Register 0 A-D0 Scan Mode Register 1 11-20
(AD0SCM0) (AD0SCM1) 11-22
H'0080 0086
A-D0 Disconnection Detection Assist Function Control Register
A-D0 Conversion Speed Control Register 11-25
(AD0DDACR) (AD0CVSCR) 11-24
H'0080 0088 A-D0 Successive Approximation Register 11-29
(AD0SAR)
H'0080 008A A-D0 Disconnection Detection Assist Method Select Register 11-26
(AD0DDASEL)
H'0080 008C A-D0 Comparate Data Register 11-30
(AD0CMP)
H'0080 008E (Use inhibited area)
H'0080 0090 10-bit A-D0 Data Register 0 11-31
(AD0DT0)
H'0080 0092 10-bit A-D0 Data Register 1 11-31
(AD0DT1)
H'0080 0094 10-bit A-D0 Data Register 2 11-31
(AD0DT2)
H'0080 0096 10-bit A-D0 Data Register 3 11-31
(AD0DT3)
H'0080 0098 10-bit A-D0 Data Register 4 11-31
(AD0DT4)
H'0080 009A 10-bit A-D0 Data Register 5 11-31
(AD0DT5)
H'0080 009C 10-bit A-D0 Data Register 6 11-31
(AD0DT6)
H'0080 009E 10-bit A-D0 Data Register 7 11-31
(AD0DT7)
H'0080 00A0 10-bit A-D0 Data Register 8 11-31
(AD0DT8)
H'0080 00A2 10-bit A-D0 Data Register 9 11-31
(AD0DT9)
H'0080 00A4 10-bit A-D0 Data Register 10 11-31
(AD0DT10)
H'0080 00A6 10-bit A-D0 Data Register 11 11-31
(AD0DT11)
H'0080 00A8 10-bit A-D0 Data Register 12 11-31
(AD0DT12)
H'0080 00AA 10-bit A-D0 Data Register 13 11-31
(AD0DT13)
H'0080 00AC 10-bit A-D0 Data Register 14 11-31
(AD0DT14)
H'0080 00AE 10-bit A-D0 Data Register 15 11-31
(AD0DT15)
| (Use inhibited area)
H'0080 00D0 (Use inhibited area) 8-bit A-D0 Data Register 0 11-32
(AD08DT0)
H'0080 00D2 (Use inhibited area) 8-bit A-D0 Data Register 1 11-32
(AD08DT1)
H'0080 00D4 (Use inhibited area) 8-bit A-D0 Data Register 2 11-32
(AD08DT2)
H'0080 00D6 (Use inhibited area) 8-bit A-D0 Data Register 3 11-32
(AD08DT3)
H'0080 00D8 (Use inhibited area) 8-bit A-D0 Data Register 4 11-32
(AD08DT4)
H'0080 00DA (Use inhibited area) 8-bit A-D0 Data Register 5 11-32
(AD08DT5)
H'0080 00DC (Use inhibited area) 8-bit A-D0 Data Register 6 11-32
(AD08DT6)
To Next Page
