11
11-14
A-D Converters
32180 Group User's Manual (Rev.1.0)
11.2 A-D Converter Related Registers
A-D Converter Related Register Map (2/3)
Address +0 address +1 address See
b0 b7 b8 b15 pages
H'0080 00DE (Use inhibited area) 8-bit A-D0 Data Register 7 11-32
(AD08DT7)
H'0080 00E0 (Use inhibited area) 8-bit A-D0 Data Register 8 11-32
(AD08DT8)
H'0080 00E2 (Use inhibited area) 8-bit A-D0 Data Register 9 11-32
(AD08DT9)
H'0080 00E4 (Use inhibited area) 8-bit A-D0 Data Register 10 11-32
(AD08DT10)
H'0080 00E6 (Use inhibited area) 8-bit A-D0 Data Register 11 11-32
(AD08DT11)
H'0080 00E8 (Use inhibited area) 8-bit A-D0 Data Register 12 11-32
(AD08DT12)
H'0080 00EA (Use inhibited area) 8-bit A-D0 Data Register 13 11-32
(AD08DT13)
H'0080 00EC (Use inhibited area) 8-bit A-D0 Data Register 14 11-32
(AD08DT14)
H'0080 00EE (Use inhibited area) 8-bit A-D0 Data Register 15 11-32
(AD08DT15)
|
H'0080 0A80 A-D1 Single Mode Register 0 A-D1 Single Mode Register 1 11-16
(AD1SIM0) (AD1SIM1) 11-18
H'0080 0A82 (Use inhibited area)
H'0080 0A84 A-D1 Scan Mode Register 0 A-D1 Scan Mode Register 1 11-20
(AD1SCM0) (AD1SCM1) 11-22
H'0080 0A86
A-D1 Disconnection Detection Assist Function Control Register
A-D1 Conversion Speed Control Register 11-25
(AD1DDACR) (AD1CVSCR) 11-24
H'0080 0A88 A-D1 Successive Approximation Register 11-29
(AD1SAR)
H'0080 0A8A A-D1 Disconnection Detection Assist Method Select Register 11-26
(AD1DDASEL)
H'0080 0A8C A-D1 Comparate Data Register 11-30
(AD1CMP)
H'0080 0A8E (Use inhibited area)
H'0080 0A90 10-bit A-D1 Data Register 0 11-31
(AD1DT0)
H'0080 0A92 10-bit A-D1 Data Register 1 11-31
(AD1DT1)
H'0080 0A94 10-bit A-D1 Data Register 2 11-31
(AD1DT2)
H'0080 0A96 10-bit A-D1 Data Register 3 11-31
(AD1DT3)
H'0080 0A98 10-bit A-D1 Data Register 4 11-31
(AD1DT4)
H'0080 0A9A 10-bit A-D1 Data Register 5 11-31
(AD1DT5)
H'0080 0A9C 10-bit A-D1 Data Register 6 11-31
(AD1DT6)
H'0080 0A9E 10-bit A-D1 Data Register 7 11-31
(AD1DT7)
H'0080 0AA0 10-bit A-D1 Data Register 8 11-31
(AD1DT8)
H'0080 0AA2 10-bit A-D1 Data Register 9 11-31
(AD1DT9)
H'0080 0AA4 10-bit A-D1 Data Register 10 11-31
(AD1DT10)
H'0080 0AA6 10-bit A-D1 Data Register 11 11-31
(AD1DT11)
H'0080 0AA8 10-bit A-D1 Data Register 12 11-31
(AD1DT12)
H'0080 0AAA 10-bit A-D1 Data Register 13 11-31
(AD1DT13)
H'0080 0AAC 10-bit A-D1 Data Register 14 11-31
(AD1DT14)
H'0080 0AAE 10-bit A-D1 Data Register 15 11-31
(AD1DT15)
| (Use inhibited area)
To Next Page
