Renesas M32R/ECU Series User Manual

11
11-15
A-D Converters
32180 Group User's Manual (Rev.1.0)
11.2 A-D Converter Related Registers
A-D Converter Related Register Map (3/3)
Adrdress +0 address +1 address See
b0 b7 b8 b15 pages
H'0080 0AD0 (Use inhibited area) 8-bit A-D1 Data Register 0 11-32
(AD18DT0)
H'0080 0AD2 (Use inhibited area) 8-bit A-D1 Data Register 1 11-32
(AD18DT1)
H'0080 0AD4 (Use inhibited area) 8-bit A-D1 Data Register 2 11-32
(AD18DT2)
H'0080 0AD6 (Use inhibited area) 8-bit A-D1 Data Register 3 11-32
(AD18DT3)
H'0080 0AD8 (Use inhibited area) 8-bit A-D1 Data Register 4 11-32
(AD18DT4)
H'0080 0ADA (Use inhibited area) 8-bit A-D1 Data Register 5 11-32
(AD18DT5)
H'0080 0ADC (Use inhibited area) 8-bit A-D1 Data Register 6 11-32
(AD18DT6)
H'0080 0ADE (Use inhibited area) 8-bit A-D1 Data Register 7 11-32
(AD18DT7)
H'0080 0AE0 (Use inhibited area) 8-bit A-D1 Data Register 8 11-32
(AD18DT8)
H'0080 0AE2 (Use inhibited area) 8-bit A-D1 Data Register 9 11-32
(AD18DT9)
H'0080 0AE4 (Use inhibited area) 8-bit A-D1 Data Register 10 11-32
(AD18DT10)
H'0080 0AE6 (Use inhibited area) 8-bit A-D1 Data Register 11 11-32
(AD18DT11)
H'0080 0AE8 (Use inhibited area) 8-bit A-D1 Data Register 12 11-32
(AD18DT12)
H'0080 0AEA (Use inhibited area) 8-bit A-D1 Data Register 13 11-32
(AD18DT13)
H'0080 0AEC (Use inhibited area) 8-bit A-D1 Data Register 14 11-32
(AD18DT14)
H'0080 0AEE (Use inhibited area) 8-bit A-D1 Data Register 15 11-32
(AD18DT15)
