10
10-164
MULTIJUNCTION TIMERS
10.8 TOU (Output-Related 24-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
10.8.6 TOU Reload Registers
The TOU reload registers are used to load data into the TOU counters. These registers are functionally different
depending on the timer’s operation mode.
(1) TOU reload registers during single-shot output, delayed single-shot output and continuous output modes
TOU0_0 Reload Register (TOU00RLW)
<Address: H'0080 0794>
TOU0_1 Reload Register (TOU01RLW)
<Address: H'0080 079C>
TOU0_2 Reload Register (TOU02RLW)
<Address: H'0080 07A4>
TOU0_3 Reload Register (TOU03RLW)
<Address: H'0080 07AC>
TOU0_4 Reload Register (TOU04RLW)
<Address: H'0080 07B4>
TOU0_5 Reload Register (TOU05RLW)
<Address: H'0080 07BC>
TOU0_6 Reload Register (TOU06RLW)
<Address: H'0080 07C4>
TOU0_7 Reload Register (TOU07RLW)
<Address: H'0080 07CC>
TOU1_0 Reload Register (TOU10RLW)
<Address: H'0080 0B94>
TOU1_1 Reload Register (TOU11RLW)
<Address: H'0080 0B9C>
TOU1_2 Reload Register (TOU12RLW)
<Address: H'0080 0BA4>
TOU1_3 Reload Register (TOU13RLW)
<Address: H'0080 0BAC>
TOU1_4 Reload Register (TOU14RLW)
<Address: H'0080 0BB4>
TOU1_5 Reload Register (TOU15RLW)
<Address: H'0080 0BBC>
TOU1_6 Reload Register (TOU16RLW)
<Address: H'0080 0BC4>
TOU1_7 Reload Register (TOU17RLW)
<Address: H'0080 0BCC>
TOU2_0 Reload Register (TOU20RLW)
<Address: H'0080 0C94>
TOU2_1 Reload Register (TOU21RLW)
<Address: H'0080 0C9C>
TOU2_2 Reload Register (TOU22RLW)
<Address: H'0080 0CA4>
TOU2_3 Reload Register (TOU23RLW)
<Address: H'0080 0CAC>
TOU2_4 Reload Register (TOU24RLW)
<Address: H'0080 0CB4>
TOU2_5 Reload Register (TOU25RLW)
<Address: H'0080 0CBC>
TOU2_6 Reload Register (TOU26RLW)
<Address: H'0080 0CC4>
TOU2_7 Reload Register (TOU27RLW)
<Address: H'0080 0CCC>
b01234567891011121314b15
T
RL
TOU17RLW, TOU20RLW–TOU27RLW
b16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 b31
????????
????????????????
<After reset: Undefined>
b Bit Name Function R W
0–7 No function assigned. Fix to "0". 00
8–31 TOU00RLW–TOU07RLW, 24-bit reload register value R W
TOU10RLW–TOU17RLW,
TOU20RLW–TOU27RLW
Note: • The 16 low-order bits must always be accessed in halfwords or more.
To Next Page
