MULTIJUNCTION TIMERS
10.3 TOP (Output-Related 16-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
10.3.6 TOP Reload Registers (TOP0RL–TOP10RL)
TOP0 Reload Register (TOP0RL)
<Address: H
’0080 0242>TOP1 Reload Register (TOP1RL)
<Address: H
’0080 0252>TOP2 Reload Register (TOP2RL)
<Address: H
’0080 0262>TOP3 Reload Register (TOP3RL)
<Address: H
’0080 0272>TOP4 Reload Register (TOP4RL)
<Address: H
’0080 0282>TOP5 Reload Register (TOP5RL)
<Address: H
’0080 0292>TOP6 Reload Register (TOP6RL)
<Address: H
’0080 02A2>TOP7 Reload Register (TOP7RL)
<Address: H
’0080 02B2>TOP8 Reload Register (TOP8RL)
<Address: H
’0080 02C2>TOP9 Reload Register (TOP9RL)
<Address: H
’0080 02D2>TOP10 Reload Register (TOP10RL)
<Address: H
’0080 02E2>b01234567891011121314b15
TOP0RL–TOP10RL
????????????????
<After reset: Undefined>
b Bit Name Function R W
0–15 TOP0RL–TOP10RL 16-bit reload register value R W
Note: • This register must always be accessed in halfwords.
The TOP reload registers are used to load data into the TOP counter registers (TOP0CT–TOP10CT). The
content of the reload register is loaded into the counter in the following cases:
• When the counter is enabled in single-shot output mode
• When the counter underflowed in delayed single-shot or continuous output mode
Simply because data is written to the reload register does not mean that the data is loaded into the counter. The
counter is loaded with data in only the above cases.
Note that reloading of data after an underflow is performed synchronously with a clock pulse at which the
counter underflowed.
