ELECTRICAL CHARACTERISTICS
32180 Group User's Manual (Rev.1.0)
Symbol Parameter Rated Value Unit See Fig.
MIN MAX 21.8.2
td(CLK-D) TXD Output Delay Time 160 ns [12]
21.8.2 Switching Characteristics
(1) Input/output ports
(2) Serial I/O
a) CSIO mode, with internal clock selected
Symbol Parameter Rated Value Unit See Fig.
MIN MAX 21.8.1
td(E-P) Port Data Output Delay Time 100 ns [3]
Symbol Parameter Rated Value Unit See Fig.
MIN MAX 21.8.2
td(CLK-D) TXD Output Delay Time 60 ns [6]
th(CLK-D) TXD Hold Time 0 ns [98]
b) CSIO mode, with external clock selected
Symbol Parameter Rated Value Unit See Fig.
MIN MAX 21.8.4
td(BCLK-TOi) TOi Output Delay Time 100 ns [15]
(3)TOi (i=0–44)
21.8 A.C. Characteristics (when VCCE = 3.3 V)
