Renesas M32R/ECU Series

10
10-161
MULTIJUNCTION TIMERS
10.8 TOU (Output-Related 24-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
10.8.5 TOU Counters
The TOU counters are functionally different depending on the timer’s operation mode.
(1) TOU counters during single-shot output, delayed single-shot output and continuous output modes
TOU0_0 Counter (TOU00CTW) <Address: H’0080 0790>
TOU0_1 Counter (TOU01CTW) <Address: H’0080 0798>
TOU0_2 Counter (TOU02CTW) <Address: H’0080 07A0>
TOU0_3 Counter (TOU03CTW) <Address: H’0080 07A8>
TOU0_4 Counter (TOU04CTW) <Address: H’0080 07B0>
TOU0_5 Counter (TOU05CTW) <Address: H’0080 07B8>
TOU0_6 Counter (TOU06CTW) <Address: H’0080 07C0>
TOU0_7 Counter (TOU07CTW) <Address: H’0080 07C8>
TOU1_0 Counter (TOU10CTW) <Address: H’0080 0B90>
TOU1_1 Counter (TOU11CTW) <Address: H’0080 0B98>
TOU1_2 Counter (TOU12CTW) <Address: H’0080 0BA0>
TOU1_3 Counter (TOU13CTW) <Address: H’0080 0BA8>
TOU1_4 Counter (TOU14CTW) <Address: H’0080 0BB0>
TOU1_5 Counter (TOU15CTW) <Address: H’0080 0BB8>
TOU1_6 Counter (TOU16CTW) <Address: H’0080 0BC0>
TOU1_7 Counter (TOU17CTW) <Address: H’0080 0BC8>
TOU2_0 Counter (TOU20CTW) <Address: H’0080 0C90>
TOU2_1 Counter (TOU21CTW) <Address: H’0080 0C98>
TOU2_2 Counter (TOU22CTW) <Address: H’0080 0CA0>
TOU2_3 Counter (TOU23CTW) <Address: H’0080 0CA8>
TOU2_4 Counter (TOU24CTW) <Address: H’0080 0CB0>
TOU2_5 Counter (TOU25CTW) <Address: H’0080 0CB8>
TOU2_6 Counter (TOU26CTW) <Address: H’0080 0CC0>
TOU2_7 Counter (TOU27CTW) <Address: H’0080 0CC8>
b01234567891011121314b15
T
OU00C
T
W
–
TOU07CTW
,
TOU10CT
W
–
–
TOU17CTW, TOU20CTW–TOU27CTW
b16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 b31
0
0
0
0
0
0
0
0
????????
????????????????
<After reset: Undefined>
b Bit Name Function R W
0–7 No function assigned. Fix to "0" 00
8–31 TOU00CTW-TOU07CTW, 24-bit counter value R W
TOU10CTW-TOU17CTW,
TOU20CTW-TOU27CTW
Note: • The 16 low-order bits must always be accessed in halfwords or more.
