Renesas M32R/ECU Series User Manual

10
10-160
MULTIJUNCTION TIMERS
10.8 TOU (Output-Related 24-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
TOU2 Control Register 0 (TOU2CR0) <Address: H’0080 0CDA>
b01234567891011121314b15
TOU20M0 TOU21M0 TOU22M0 TOU23M0 TOU24M0 TOU25M0 TOU26M0 TOU27M0
0000000000000000
<After reset: H’0000>
b Bit Name Function R W
0, 1 TOU20M0 (TOU2_0 operation mode select 0 bit) 00: Single-shot output mode R W
2, 3 TOU21M0 (TOU2_1 operation mode select 0 bit) 01: Single-shot PWM output mode
4, 5 TOU22M0 (TOU2_2 operation mode select 0 bit) or delayed single-shot output mode (Note 1)
6, 7 TOU23M0 (TOU2_3 operation mode select 0 bit) 10: Continuous output mode
8, 9 TOU24M0 (TOU2_4 operation mode select 0 bit) 11: PWM output mode
10, 11 TOU25M0 (TOU2_5 operation mode select 0 bit)
12, 13 TOU26M0 (TOU2_6 operation mode select 0 bit)
14, 15 TOU27M0 (TOU2_7 operation mode select 0 bit)
Note 1: Use TOU2 Control Register 1 to select between these two modes.
Notes: • This register must always be accessed in halfwords.
• Operation mode can only be set or changed while the counter is inactive.
TOU2 Control Register 1 (TOU2CR1) <Address: H’0080 0CD8>
b01234567891011121314b15
TOU2CKS TOU20M1 TOU21M1 TOU22M1 TOU23M1 TOU25M1 TOU26M1 TOU27M1TOU24M1
0
0
0
0
0
0
0
0
00000000
<After reset: H’0000>
b Bit Name Function R W
0 TOU2CKS 0: Use prescaler 5 R W
TOU2 clock source select bit 1: Use external clock (TIN28)
1–7 No function assigned. Fix to "0". 00
8 TOU20M1 (TOU2_0 operation mode select 1 bit) 0: Single-shot PWM output mode R W
9 TOU21M1 (TOU2_1 operation mode select 1 bit) 1: Delayed single-shot output mode
10 TOU22M1 (TOU2_2 operation mode select 1 bit)
11 TOU23M1 (TOU2_3 operation mode select 1 bit)
12 TOU24M1 (TOU2_4 operation mode select 1 bit)
13 TOU25M1 (TOU2_5 operation mode select 1 bit)
14 TOU26M1 (TOU2_6 operation mode select 1 bit)
15 TOU27M1 (TOU2_7 operation mode select 1 bit)
Notes: • This register must always be accessed in halfwords.
• Operation mode can only be set or changed while the counter is inactive.
TOU2 Control Registers 0 and 1 are used to select operation modes of TOU2_0–7.
To select prescaler 5 as the clock source for TOU2, make sure the TID2 Control & Prescaler 5 Enable Register’s
prescaler 5 enable bit is set to "1". For details, see Section 10.7.3, “TID Control & Prescaler Enable Registers.”
