Renesas M32R/ECU Series User Manual

10
10-168
MULTIJUNCTION TIMERS
10.8 TOU (Output-Related 24-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
10.8.7 TOU Enable Protect Registers
TOU0 Enable Protect Register (TOU0PRO) <Address: H'0080 07DD>
TOU1 Enable Protect Register (TOU1PRO) <Address: H'0080 0BDD>
TOU2 Enable Protect Register (TOU2PRO) <Address: H'0080 0CDD>
9 1011121314b15b8
TOUn
0PRO
TOUn
1PRO
TOUn
2PRO
TOUn
3PRO
TOUn
4PRO
TOUn
5PRO
TOUn
6PRO
TOUn
7PRO
00000000
<After reset: H’00>
b Bit Name Function R W
8 TOUn0PRO 0: Enable rewrite R W
TOUn_0 enable protect bit 1: Disable rewrite
9 TOUn1PRO
TOUn_1 enable protect bit
10 TOUn2PRO
TOUn_2 enable protect bit
11 TOUn3PRO
TOUn_3 enable protect bit
12 TOUn4PRO
TOUn_4 enable protect bit
13 TOUn5PRO
TOUn_5 enable protect bit
14 TOUn6PRO
TOUn_6 enable protect bit
15 TOUn7PRO
TOUn_7 enable protect bit
The TOU enable protect registers control rewriting of the TOU count enable bit described in Section 10.8.8,
“TOU Count Enable Registers,” by enabling or disabling rewrite.
