A-D Converters
32180 Group User's Manual (Rev.1.0)
11.2.11 8-bit A-D Data Registers
8-bit A-D0 Data Register 0(AD08DT0)
<Address: H
’0080 00D1>8-bit A-D0 Data Register 1(AD08DT1)
<Address: H
’0080 00D3>8-bit A-D0 Data Register 2(AD08DT2)
<Address: H
’0080 00D5>8-bit A-D0 Data Register 3(AD08DT3)
<Address: H
’0080 00D7>8-bit A-D0 Data Register 4(AD08DT4)
<Address: H
’0080 00D9>8-bit A-D0 Data Register 5(AD08DT5)
<Address: H
’0080 00DB>8-bit A-D0 Data Register 6(AD08DT6)
<Address: H
’0080 00DD>8-bit A-D0 Data Register 7(AD08DT7)
<Address: H
’0080 00DF>8-bit A-D0 Data Register 8(AD08DT8)
<Address: H
’0080 00E1>8-bit A-D0 Data Register 9(AD08DT9)
<Address: H
’0080 00E3>8-bit A-D0 Data Register 10(AD08DT10)
<Address: H
’0080 00E5>8-bit A-D0 Data Register 11(AD08DT11)
<Address: H
’0080 00E7>8-bit A-D0 Data Register 12(AD08DT12)
<Address: H
’0080 00E9>8-bit A-D0 Data Register 13(AD08DT13)
<Address: H
’0080 00EB>8-bit A-D0 Data Register 14(AD08DT14)
<Address: H
’0080 00ED>8-bit A-D0 Data Register 15(AD08DT15)
<Address: H
’0080 00EF>8-bit A-D1 Data Register 0(AD18DT0)
<Address: H
’0080 0AD1>8-bit A-D1 Data Register 1(AD18DT1)
<Address: H
’0080 0AD3>8-bit A-D1 Data Register 2(AD18DT2)
<Address: H
’0080 0AD5>8-bit A-D1 Data Register 3(AD18DT3)
<Address: H
’0080 0AD7>8-bit A-D1 Data Register 4(AD18DT4)
<Address: H
’0080 0AD9>8-bit A-D1 Data Register 5(AD18DT5)
<Address: H
’0080 0ADB>8-bit A-D1 Data Register 6(AD18DT6)
<Address: H
’0080 0ADD>8-bit A-D1 Data Register 7(AD18DT7)
<Address: H
’0080 0ADF>8-bit A-D1 Data Register 8(AD18DT8)
<Address: H
’0080 0AE1>8-bit A-D1 Data Register 9(AD18DT9)
<Address: H
’0080 0AE3>8-bit A-D1 Data Register 10(AD18DT10)
<Address: H
’0080 0AE5>8-bit A-D1 Data Register 11(AD18DT11)
<Address: H
’0080 0AE7>8-bit A-D1 Data Register 12(AD18DT12)
<Address: H
’0080 0AE9>8-bit A-D1 Data Register 13(AD18DT13)
<Address: H
’0080 0AEB>8-bit A-D1 Data Register 14(AD18DT14)
<Address: H
’0080 0AED>8-bit A-D1 Data Register 15(AD18DT15)
<Address: H
’0080 0AEF>9 1011121314b15b8
AD08DT0-AD08DT15, AD18DT0-AD18DT15
????????
<After reset: Undefined>
b Bit Name Function R W
8–15 AD08DT0-AD08DT15, AD18DT0-AD18DT15 8-bit A-D conversion result R –
8-bit A-D data
During single mode, the 8-bit A-D Data Registers are used to store the result of A-D conversion performed on
each corresponding channel.
During single-shot or continuous scan mode, the content of the A-D Successive Approximation Register is
transferred to the 8-bit A-D Data Register for the corresponding channel when A-D conversion on each channel
has finished. Each 8-bit A-D Data Register retains the last conversion result until they receive the next conver-
sion result transferred, allowing the content to be read out at any time.
11.2 A-D Converter Related Registers
