10
10-10
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
10.2.1 MJT Common Unit Register Map
The table below shows a common unit register map of MJT.
MJT Common Unit Register Map (1/2)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0200 (Use inhibited area) Clock Bus & Input Event Bus Control Register 10-16
(CKIEBCR)
H'0080 0202 Prescaler Register 0 Prescaler Register 1 10-12
(PRS0) (PRS1)
H'0080 0204 Prescaler Register 2 Output Event Bus Control Register 10-12
(PRS2) (OEBCR) 10-17
(Use inhibited area)
H'0080 0210 TCLK Input Processing Control Register 10-20
(TCLKCR)
H'0080 0212 TIN0–4 Input Processing Control Register 10-21
(TIN04CR)
H'0080 0214 TIN5–8 Input Processing Control Register 10-22
(TIN58CR)
H'0080 0216 TIN9–11 Input Processing Control Register 10-23
(TIN911CR)
H'0080 0218 TIN12–19 Input Processing Control Register 10-24
(TIN1219CR)
H'0080 021A TIN20–23, TIN30–33 Input Processing Control Register 10-24
(TIN2023_3033CR)
(Use inhibited area)
H'0080 0220 F/F6–15 Source Select Register 10-28
(FF615S)
H'0080 0222 (Use inhibited area) F/F16–19 Source Select Register 10-29
(FF1619S)
H'0080 0224 F/F0–15 Protect Register 10-30
(FF015P)
H'0080 0226 F/F0–15 Data Register 10-32
(FF015D)
H'0080 0228 (Use inhibited area) F/F16–20 Protect Register 10-30
(FF1620P)
H'0080 022A (Use inhibited area) F/F16–20 Data Register 10-32
(FF1620D)
(Use inhibited area)
H'0080 0230 TOP0–5 Interrupt Request Status Register TOP0–5 Interrupt Request Mask Register 10-39
(TOP05IST) (TOP05IMA)
H'0080 0232 TOP6,7 Interrupt Request Mask & Status Register TOP8,9 Interrupt Request Mask & Status Register 10-41
(TOP67IMS) (TOP89IMS) 10-42
H'0080 0234 TIO0–3 Interrupt Request Mask & Status Register TIO4–7 Interrupt Request Mask & Status Register 10-43
(TIO03IMS) (TIO47IMS) 10-44
H'0080 0236 TIO8,9 Interrupt Request Mask & Status Register TMS0,1 Interrupt Request Mask & Status Register 10-45
(TIO89IMS) (TMS01IMS) 10-46
H'0080 0238 TIN0–2 Interrupt Request Mask & Status Register TIN3–6 Interrupt Request Mask & Status Register 10-47
(TIN02IMS) (TIN36IMS) 10-48
H'0080 023A TIN7–11 Interrupt Request Status Register TIN7–11 Interrupt Request Mask Register 10-49
(TIN711IST) (TIN711IMA)
H'0080 023C TIN12–19 Interrupt Request Status Register TIN12–19 Interrupt Request Mask Register 10-51
(TIN1219IST) (TIN1219IMA)
H'0080 023E TIN20–23 Interrupt Request Mask & Status Register TIN30–33 Interrupt Request Mask & Status Register 10-53
(TIN2023IMS) (TIN3033IMS) 10-57
H'0080 07D0 Prescaler Register 3 TID0 Control & Prescaler 3 Enable Register 10-12
(PRS3) (TID0PRS3EN) 10-141
H'0080 07D2 TOU0 Interrupt Request Mask Register TOU0 Interrupt Request Status Register 10-58
(TOU0IMA) (TOU0IST)
H'0080 07D4 (Use inhibited area) F/F21–28 Protect Register 10-31
(FF2128P)
H'0080 07D6 (Use inhibited area) F/F21–28 Data Register 10-33
(FF2128D)
|
|
|
|
|
To Next Page
