10
10-11
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
MJT Common Unit Register Map (2/2)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 07E0 PWMOFF0 Input Processing Control Register TIN24,25 Input Processing Control Register 10-171
(PWMOFF0CR) (TIN2425CR) 10-25
H'0080 07E2 TIN24,25 Interrupt Request Mask Register TIN24,25 Interrupt Request Status Register 10-53
(TIN2425IMA) (TIN2425IST)
H'0080 0BD0 Prescaler Register 4 TID1 Control & Prescaler 4 Enable Register 10-12
(PRS4) (TID1PRS4EN) 10-142
H'0080 0BD2 TOU1 Interrupt Request Mask Register TOU1 Interrupt Request Status Register 10-60
(TOU1IMA) (TOU1IST)
H'0080 0BD4 (Use inhibited area) F/F29–36 Protect Register 10-31
(FF2936P)
H'0080 0BD6 (Use inhibited area) F/F29–36 Data Register 10-33
(FF2936D)
H'0080 0BE0 PWMOFF1 Input Processing Control Register TIN26,27 Input Processing Control Register 10-171
(PWMOFF1CR) (TIN2627CR) 10-25
H'0080 0BE2 TIN26,27 Interrupt Request Mask Register TIN26,27 Interrupt Request Status Register 10-54
(TIN2627IMA) (TIN2627IST)
H'0080 0CD0 Prescaler Register 5 TID2 Control & Prescaler 5 Enable Register 10-12
(PRS5) (TID2PRS5EN) 10-143
H'0080 0CD2 TOU2 Interrupt Request Mask Register TOU2 Interrupt Request Status Register 10-61
(TOU2IMA) (TOU2IST)
H'0080 0CD4 (Use inhibited area) F/F37–44 Protect Register 10-31
(FF3744P)
H'0080 0CD6 (Use inhibited area) F/F37–44 Data Register 10-34
(FF3744D)
H'0080 0CE0 PWMOFF2 Input Processing Control Register TIN28,29 Input Processing Control Register 10-172
(PWMOFF2CR) (TIN2829CR) 10-25
H'0080 0CE2 TIN28,29 Interrupt Request Mask Register TIN28,29 Interrupt Request Status Register 10-54
(TIN2829IMA) (TIN2829IST)
|
|
|
|
To Next Page
