Renesas M32R/ECU Series User Manual

11
11-31
A-D Converters
32180 Group User's Manual (Rev.1.0)
11.2.10 10-bit A-D Data Registers
10-bit A-D0 Data Register 0(AD0DT0) <Address: H’0080 0090>
10-bit A-D0 Data Register 1(AD0DT1) <Address: H’0080 0092>
10-bit A-D0 Data Register 2(AD0DT2) <Address: H’0080 0094>
10-bit A-D0 Data Register 3(AD0DT3) <Address: H’0080 0096>
10-bit A-D0 Data Register 4(AD0DT4) <Address: H’0080 0098>
10-bit A-D0 Data Register 5(AD0DT5) <Address: H’0080 009A>
10-bit A-D0 Data Register 6(AD0DT6) <Address: H’0080 009C>
10-bit A-D0 Data Register 7(AD0DT7) <Address: H’0080 009E>
10-bit A-D0 Data Register 8(AD0DT8) <Address: H’0080 00A0>
10-bit A-D0 Data Register 9(AD0DT9) <Address: H’0080 00A2>
10-bit A-D0 Data Register 10(AD0DT10) <Address: H’0080 00A4>
10-bit A-D0 Data Register 11(AD0DT11) <Address: H’0080 00A6>
10-bit A-D0 Data Register 12(AD0DT12) <Address: H’0080 00A8>
10-bit A-D0 Data Register 13(AD0DT13) <Address: H’0080 00AA>
10-bit A-D0 Data Register 14(AD0DT14) <Address: H’0080 00AC>
10-bit A-D0 Data Register 15(AD0DT15) <Address: H’0080 00AE>
10-bit A-D1 Data Register 0(AD1DT0) <Address: H’0080 0A90>
10-bit A-D1 Data Register 1(AD1DT1) <Address: H’0080 0A92>
10-bit A-D1 Data Register 2(AD1DT2) <Address: H’0080 0A94>
10-bit A-D1 Data Register 3(AD1DT3) <Address: H’0080 0A96>
10-bit A-D1 Data Register 4(AD1DT4) <Address: H’0080 0A98>
10-bit A-D1 Data Register 5(AD1DT5) <Address: H’0080 0A9A>
10-bit A-D1 Data Register 6(AD1DT6) <Address: H’0080 0A9C>
10-bit A-D1 Data Register 7(AD1DT7) <Address: H’0080 0A9E>
10-bit A-D1 Data Register 8(AD1DT8) <Address: H’0080 0AA0>
10-bit A-D1 Data Register 9(AD1DT9) <Address: H’0080 0AA2>
10-bit A-D1 Data Register 10(AD1DT10) <Address: H’0080 0AA4>
10-bit A-D1 Data Register 11(AD1DT11) <Address: H’0080 0AA6>
10-bit A-D1 Data Register 12(AD1DT12) <Address: H’0080 0AA8>
10-bit A-D1 Data Register 13(AD1DT13) <Address: H’0080 0AAA>
10-bit A-D1 Data Register 14(AD1DT14) <Address: H’0080 0AAC>
10-bit A-D1 Data Register 15(AD1DT15) <Address: H’0080 0AAE>
b01234567891011121314b15
AD0DT0-AD0DT15, AD1DT0-AD1DT15
0
0
0
0
0
0
??????????
<After reset: Undefined>
b Bit Name Function R W
0–5 No function assigned. 0 –
6–15 AD0DT0-AD0DT15, AD1DT0-AD1DT15 10-bit A-D conversion result R –
10-bit A-D data
Note: • This register must always be accessed in halfwords.
During single mode, the 10-bit A-D Data Registers are used to store the result of A-D conversion performed on
each corresponding channel.
During single-shot or continuous scan mode, the content of the A-D Successive Approximation Register is
transferred to the 10-bit A-D Data Register for the corresponding channel when A-D conversion on each channel
has finished. Each 10-bit A-D Data Register retains the last conversion result until they receive the next conver-
sion result transferred, allowing the content to be read out at any time.
11.2 A-D Converter Related Registers
