MULTIJUNCTION TIMERS
10.8 TOU (Output-Related 24-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
10.8.10 PWM Output Control Registers
PWM Output 0 Disable Control Register (PO0DISCR) <Address: H’0080 0780>
123456b7b0
PO0DIS PO0DISP
00
0
0
0
0
0
0
<After reset: H’00>
b Bit Name Function R W
0–5 No function assigned. Fix to "0". 00
6 PO0DISP – 0W
PO0DIS write control bit
7 PO0DIS 0: Enable output R W
P160/TO21–P165/TO26 output disable select bit 1: Disable output
PWM Output 1 Disable Control Register (PO1DISCR) <Address: H'0080 0782>
123456b7b0
PO1DIS PO1DISP
00
0
0
0
0
0
0
<After reset: H’00>
b Bit Name Function R W
0–5 No function assigned. Fix to "0". 00
6 PO1DISP – 0W
PO1DIS write control bit
7 PO1DIS 0: Enable output R W
P180/TO29–P185/TO34 output disable select bit 1: Disable output
