MULTIJUNCTION TIMERS
10.6 TML (Input-Related 32-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
10.6.5 TML Counters
TML0 Counter (TML0CT) <Address: H’0080 03E0>
TML1 Counter (TML1CT) <Address: H’0080 0FE0>
b01234567891011121314b15
TML0CT, TML1CT(16 high-order bits)
b16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 b31
(16 low-order bits)
????????????????
????????????????
<After reset: Undefined>
b Bit Name Function R W
0–31 TML0CT 32-bit counter value R(Note 1)
Note 1: If the clock source selected for the counter is not BCLK/2, do not write to this register.
Note: • This register must always be accessed wordwise (in 32 bits) beginning with the word boundary.
The TML counters are a 32-bit up-counter, which starts counting upon deassertion of the reset input signal. The
counters can be read on-the-fly.
10.6.6 TML Measure Registers
TML0 Measure 3 Register (TML0MR3) <Address: H’0080 03F0>
TML0 Measure 2 Register (TML0MR2) <Address: H’0080 03F4>
TML0 Measure 1 Register (TML0MR1) <Address: H’0080 03F8>
TML0 Measure 0 Register (TML0MR0) <Address: H’0080 03FC>
TML1 Measure 3 Register (TML1MR3) <Address: H’0080 0FF0>
TML1 Measure 2 Register (TML1MR2) <Address: H’0080 0FF4>
TML1 Measure 1 Register (TML1MR1) <Address: H’0080 0FF8>
TML1 Measure 0 Register (TML1MR0) <Address: H’0080 0FFC>
b01234567891011121314b15
TML0MR3–TML0MR0, TML1MR3–TML1MR0 (16 high-order bits)
b16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
(16 low-order bits)
????????????????
????????????????
<After reset: Undefined>
b Bit Name Function R W
0–31 TML0MR3–TML0MR0, TML1MR3–TML1MR0 32-bit measure register value R –
Notes: • These registers are a read-only register.
• These registers must always be accessed wordwise (in 32 bits) beginning with the word boundary.
The TML measure registers are a 32-bit register, which is used to latch the counter content upon event input.
The TML measure registers can only be read, and cannot be written to.
