13-21
13
32180 Group User’s Manual (Rev.1.0)
13.2 CAN Module Related Registers
CAN MODULE
13.2.3 CAN Frame Format Select Registers
CAN0 Frame Format Select Register (CAN0FFS)
<Address: H
’0080 1004>CAN1 Frame Format Select Register (CAN1FFS)
<Address: H
’0080 1404>b0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 b15
FFE0 FFE1 FFE2 FFE3 FFE4 FFE6 FFE7 FFE8 FFE9 FFE10 FFE11 FFE12 FFE13 FFE14 FFE15FFE5
0000000000000000
<After reset: H’0000>
b Bit Name Function R W
0 FFE0 (slot 0 extended format bit) 0: Standard ID format R W
1 FFE1 (slot 1 extended format bit) 1: Extended ID format
2 FFE2 (slot 2 extended format bit)
3 FFE3 (slot 3 extended format bit)
4 FFE4 (slot 4 extended format bit)
5 FFE5 (slot 5 extended format bit)
6 FFE6 (slot 6 extended format bit)
7 FFE7 (slot 7 extended format bit)
8 FFE8 (slot 8 extended format bit)
9 FFE9 (slot 9 extended format bit)
10 FFE10 (slot 10 extended format bit)
11 FFE11 (slot 11 extended format bit)
12 FFE12 (slot 12 extended format bit)
13 FFE13 (slot 13 extended format bit)
14 FFE14 (slot 14 extended format bit)
15 FFE15 (slot 15 extended format bit)
This register selects the format of frames handled by message slots corresponding to the respective bits in the
register. Setting any bit in this register to "0" selects the standard ID format, and setting any bit in this register to
"1" selects the extended ID format.
Note: • Settings of any bit in this register can only be changed when the corresponding slot does not
have transmit or receive requests set.
To Next Page
