MULTIJUNCTION TIMERS
10.7 TID (Input-Related 16-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
10.7.3 TID Control & Prescaler Enable Registers
TID0 Control & Prescaler 3 Enable Register
(TID0PRS3EN) <Address: H
’0080 07D1>9 1011121314b15b8
TID0M TID0CEN TOU0ENS PRS3EN
00000000
<After reset: H’00>
b Bit Name Function R W
8–10 TID0M 000: Fixed period count mode R W
TID0 operation mode select bit 001: – ditto–
010: Multiply-by-4 event count mode
011: Event count mode
100: Fixed period count mode
101: – ditto –
110: Multiply-by-4 event count mode
111: Up/down event count mode
11 TID0CEN 0: Stop TID0 count R W
TID0 count enable bit 1: Start TID0 count
12–14 TOU0ENS 000: Disable event enable R W
TOU0 enable source select bit 001: – ditto –
010: TID0 underflow/overflow
011: TOU0_7 underflow
100: Disable event enable
101: – ditto –
110: Output event bus 0
111: External input TIN25 signal
15 PRS3EN 0: Stop count R W
Prescaler 3 enable bit 1: Start count
Note: • Operation mode can only be set or changed while the counter is inactive.
The TID0 Control & Prescaler 3 Enable Register is used to select TID0 operation mode (Fixed period count,
Event count, Multiply-by-4 event count or Up/down event count mode), as well as select TOU0_0–7 timer enable
sources and control prescaler 3 startup.
