Renesas M32R/ECU Series User Manual

11
11-26
A-D Converters
32180 Group User's Manual (Rev.1.0)
11.2 A-D Converter Related Registers
11.2.7 A-D Disconnection Detection Assist Method Select Registers
A-D0 Disconnection Detection Assist Method Select Register (AD0DDASEL) <Address: H’0080 008A>
A-D1 Disconnection Detection Assist Method Select Register (AD1DDASEL) <Address: H’0080 0A8A>
b01234567891011121314b15
ADDDA
SEL0
ADDDA
SEL1
ADDDA
SEL2
ADDDA
SEL3
ADDDA
SEL4
ADDDA
SEL6
ADDDA
SEL7
ADDDA
SEL8
ADDDA
SEL9
ADDDA
SEL10
ADDDA
SEL11
ADDDA
SEL12
ADDDA
SEL13
ADDDA
SEL14
ADDDA
SEL15
ADDDA
SEL5
????????????????
<After reset: Undefined>
b Bit Name Function R W
0 ADDDASEL0 0: Discharge before conversion R W
Channel 0 disconnection detection assist method select bit 1: Precharge before conversion
1 ADDDASEL1
Channel 1 disconnection detection assist method select bit
2 ADDDASEL2
Channel 2 disconnection detection assist method select bit
3 ADDDASEL3
Channel 3 disconnection detection assist method select bit
4 ADDDASEL4
Channel 4 disconnection detection assist method select bit
5 ADDDASEL5
Channel 5 disconnection detection assist method select bit
6 ADDDASEL6
Channel 6 disconnection detection assist method select bit
7 ADDDASEL7
Channel 7 disconnection detection assist method select bit
8 ADDDASEL8
Channel 8 disconnection detection assist method select bit
9 ADDDASEL9
Channel 9 disconnection detection assist method select bit
10 ADDDASEL10
Channel 10 disconnection detection assist method select bit
11 ADDDASEL11
Channel 11 disconnection detection assist method select bit
12 ADDDASEL12
Channel 12 disconnection detection assist method select bit
13 ADDDASEL13
Channel 13 disconnection detection assist method select bit
14 ADDDASEL14
Channel 14 disconnection detection assist method select bit
15 ADDDASEL15
Channel 15 disconnection detection assist method select bit
Notes: • This register must always be accessed in halfwords.
• For these bits to be enabled, the ADDDAEN bit (A-D Disconnection Detection Assist Function Control Register bit 7) must
be set to "1" before setting these bits.
In order to prevent the A-D conversion result from being affected by the analog input voltage wrapping around
from any preceding channel, the A-D Disconnection Detection Assist Method Select Registers are used to
control the conversion start state by selecting whether to discharge or precharge the chopper amp capacitor
before starting regular conversion operation.
