MULTIJUNCTION TIMERS
10.3 TOP (Output-Related 16-Bit Timer)
32180 Group User’s Manual (Rev.1.0)
TOP Related Register Map (2/2)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 029A TOP0–5 Control Register 0 10-71
(TOP05CR0)
H'0080 029C (Use inhibited area) TOP0–5 Control Register 1 10-71
(TOP05CR1)
(Use inhibited area)
H'0080 02A0 TOP6 Counter 10-75
(TOP6CT)
H'0080 02A2 TOP6 Reload Register 10-76
(TOP6RL)
H'0080 02A4 (Use inhibited area)
H'0080 02A6 TOP6 Correction Register 10-77
(TOP6CC)
H'0080 02A8 (Use inhibited area)
H'0080 02AA TOP6,7 Control Register 10-73
(TOP67CR)
(Use inhibited area)
H'0080 02B0 TOP7 Counter 10-75
(TOP7CT)
H'0080 02B2 TOP7 Reload Register 10-76
(TOP7RL)
H'0080 02B4 (Use inhibited area)
H'0080 02B6 TOP7 Correction Register 10-77
(TOP7CC)
(Use inhibited area)
H'0080 02C0 TOP8 Counter 10-75
(TOP8CT)
H'0080 02C2 TOP8 Reload Register 10-76
(TOP8RL)
H'0080 02C4 (Use inhibited area)
H'0080 02C6 TOP8 Correction Register 10-77
(TOP8CC)
(Use inhibited area)
H'0080 02D0 TOP9 Counter 10-75
(TOP9CT)
H'0080 02D2 TOP9 Reload Register 10-76
(TOP9RL)
H'0080 02D4 (Use inhibited area)
H'0080 02D6 TOP9 Correction Register 10-77
(TOP9CC)
(Use inhibited area)
H'0080 02E0 TOP10 Counter 10-75
(TOP10CT)
H'0080 02E2 TOP10 Reload Register 10-76
(TOP10RL)
H'0080 02E4 (Use inhibited area)
H'0080 02E6 TOP10 Correction Register 10-77
(TOP10CC)
H'0080 02E8 (Use inhibited area)
H'0080 02EA TOP8–10 Control Register 10-74
(TOP810CR)
(Use inhibited area)
H'0080 02FA TOP External Enable Permit Register 10-78
(TOPEEN)
H'0080 02FC TOP Enable Protect Register 10-78
(TOPPRO)
H'0080 02FE TOP Count Enable Register 10-79
(TOPCEN)
|
|
|
|
|
|
