3-37

ADDRESS SPACE

32180 Group User’s Manual (Rev.1.0)

3.6 ICU Vector Table

ICU Vector Table Memory Map (2/2)

Address +0 address +1 address

b0 b7 b8 b15

H'0000 00D8 SIO0 Transmit Interrupt Handler Start Address (A0–A15)

H'0000 00DA SIO0 Transmit Interrupt Handler Start Address (A16–A31)

H'0000 00DC A-D0 Conversion Interrupt Handler Start Address (A0–A15)

H'0000 00DE A-D0 Conversion Interrupt Handler Start Address (A16–A31)

H'0000 00E0 TID0 Input Interrupt Handler Start Address (A0–A15)

H'0000 00E2 TID0 Input Interrupt Handler Start Address (A16–A31)

H'0000 00E4 TOU0 Output Interrupt Handler Start Address (A0–A15)

H'0000 00E6 TOU0 Output Interrupt Handler Start Address (A16–A31)

H'0000 00E8 DMA5–9 Interrupt Handler Start Address (A0–A15)

H'0000 00EA DMA5–9 Interrupt Handler Start Address (A16–A31)

H'0000 00EC SIO2, 3 Transmit/receive Interrupt Handler Start Address (A0–A15)

H'0000 00EE SIO2, 3 Transmit/receive Interrupt Handler Start Address (A16–A31)

H'0000 00F0 RTD Interrupt Handler Start Address (A0–A15)

H'0000 00F2 RTD Interrupt Handler Start Address (A16–A31)

H'0000 00F4 TID1 Input Interrupt Handler Start Address (A0–A15)

H'0000 00F6 TID1 Input Interrupt Handler Start Address (A16–A31)

H'0000 00F8 TOU1 + TOU2 Output Interrupt Handler Start Address (A0–A15)

H'0000 00FA TOU1 + TOU2 Output Interrupt Handler Start Address (A16–A31)

H'0000 00FC SIO4, 5 Transmit/receive Interrupt Handler Start Address (A0–A15)

H'0000 00FE SIO4, 5 Transmit/receive Interrupt Handler Start Address (A16–A31)

H'0000 0100 A-D1 Conversion Interrupt Handler Start Address (A0–A15)

H'0000 0102 A-D1 Conversion Interrupt Handler Start Address (A16–A31)

H'0000 0104 TID2 Input Interrupt Handler Start Address (A0–A15)

H'0000 0106 TID2 Input Interrupt Handler Start Address (A16–A31)

H'0000 0108 TIN30–33 Input Interrupt Handler Start Address (A0–A15)

H'0000 010A TIN30–33 Input Interrupt Handler Start Address (A16–A31)

H'0000 010C CAN0 Transmit/receive & Error Interrupt Handler Start Address (A0–A15)

H'0000 010E CAN0 Transmit/receive & Error Interrupt Handler Start Address (A16–A31)

H'0000 0110 CAN1 Transmit/receive & Error Interrupt Handler Start Address (A0–A15)

H'0000 0112 CAN1 Transmit/receive & Error Interrupt Handler Start Address (A16–A31)
