Figure 6.4.2 Example of FCNT4 Register Operation 1 (Clearing each status of the FSTAT2 register)
FRESET = 1
YES
NO
FENTRY = 1
Program/erase
the flash memory
Error found
FRESET = 0
Program/erase
the flash memory
FENTRY = 0
* At this point in time,
the FSTAT1 register FSTAT bit = 1 (ready).
Programming/erase
operation terminated normally
6.4 Registers Associated with the Internal Flash Memory
FRESET = 1
FRESET = 0
Forcibly terminate
Flash programming/erase operation has timed out
Figure 6.4.3 Example of FCNT4 Register Operation 2 (Forcibly terminating operation when programming/
erasing the internal flash memory)
