8
8-6
INPUT/OUTPUT PORTS AND PIN FUNCTIONS
32180 Group User’s Manual (Rev.1.0)
Input/Output Port Related Register Map (2/2)
Address +0 address +1 address See pages
b0 b7 b8 b15
H'0080 0740 P0 Operation Mode Register P1 Operation Mode Register 8-9
(P0MOD) (P1MOD)
H'0080 0742 P2 Operation Mode Register P3 Operation Mode Register 8-10
(P2MOD) (P3MOD)
H'0080 0744 P4 Operation Mode Register Port Input Special Function Control Register 8-11
(P4MOD) (PICNT) 8-21
H'0080 0746 P6 Operation Mode Register P7 Operation Mode Register 8-11
(P6MOD) (P7MOD) 8-12
H'0080 0748 P8 Operation Mode Register P9 Operation Mode Register 8-12
(P8MOD) (P9MOD) 8-13
H'0080 074A P10 Operation Mode Register P11 Operation Mode Register 8-13
(P10MOD) (P11MOD) 8-14
H'0080 074C P12 Operation Mode Register P13 Operation Mode Register 8-14
(P12MOD) (P13MOD) 8-15
H'0080 074E P14 Operation Mode Register P15 Operation Mode Register 8-15
(P14MOD) (P15MOD) 8-16
H'0080 0750 P16 Operation Mode Register P17 Operation Mode Register 8-16
(P16MOD) (P17MOD) 8-17
H'0080 0752 P18 Operation Mode Register P19 Operation Mode Register 8-17
(P18MOD) (P19MOD) 8-18
H'0080 0754 P20 Operation Mode Register P21 Operation Mode Register 8-18
(P20MOD) (P21MOD) 8-19
H'0080 0756 P22 Operation Mode Register (Use inhibited area) 8-19
(P22MOD)
(Use inhibited area)
H'0080 0760 Port Group 0,1 Input Level Setting Register Port Group 2,3 Input Level Setting Register 8-25
(PG01LEV) (PG23LEV)
H'0080 0762 Port Group 4,5 Input Level Setting Register Port Group 6,7 Input Level Setting Register 8-25
(PG45LEV) (PG67LEV)
H'0080 0764 Port Group 8 Input Level Setting Register (Use inhibited area) 8-25
(PG8LEV)
(Use inhibited area)
H'0080 076A P10 Peripheral Output Select Register (Use inhibited area) 8-20
(P10SMOD)
(Use inhibited area)
H'0080 0776 P22 Peripheral Output Select Register (Use inhibited area) 8-20
(P22SMOD)
8.3 Input/Output Port Related Registers
|
|
|
