10-40

MULTIJUNCTION TIMERS

10.2 Common Units of Multijunction Timers

32180 Group User’s Manual (Rev.1.0)

TOP0-5 output interrupt request

IRQ2

Data bus

TOPIS5

F/F

TOPIM5

F/F

b10

TOPIS4

F/F

TOPIM4

F/F

b11

TOPIS3

F/F

TOPIM3

F/F

b12

TOPIS2

F/F

TOPIM2

F/F

b13

TOPIS1

F/F

TOPIM1

F/F

b14

TOPIS0

F/F

TOPIM0

F/F

b15

(Level)

6-source inputs

TOP05IST <H'0080 0230>

TOP05IMA <H'0080 0231>

TOP5udf

TOP4udf

TOP3udf

TOP2udf

TOP1udf

TOP0udf

Figure 10.2.5 Block Diagram of TOP0–5 Output Interrupt Request
