Page #30 background image
1
1-13
OVERVIEW
32180 Group Users Manual (Rev.1.0)
1.3 Pin Functions
Table 1.3.1 Description of Pin Functions (5/5)
Type Pin Name Signal Name Input/Output Description
Input/output P00P07 Input/output port 0 Input/output Programmable input/output port.
ports P10P17 Input/output port 1
(Note 1) P20P27 Input/output port 2
P30P37 Input/output port 3
P41P47 Input/output port 4
P61P63 Input/output port 6
P65P67
P70P77 Input/output port 7
P82P87 Input/output port 8
P93P97 Input/output port 9
P100P107 Input/output port 10
P110P117 Input/output port 11
P124P127 Input/output port 12
P130P137 Input/output port 13
P140P147 Input/output port 14
P150P157 Input/output port 15
P160P167 Input/output port 16
P172P177 Input/output port 17
P180P187 Input/output port 18
P190P197 Input/output port 19
P200P203 Input/output port 20
P210P217 Input/output port 21
P220P227 Input/output port 22
Note 1: Input/output port 5 is reserved for future use. P221 and P223 are input-only ports.
