10-100

10.4 TIO (Input/Output-Related 16-Bit Timer)

MULTIJUNCTION TIMERS

32180 Group User’s Manual (Rev.1.0)

TIO Related Register Map (2/2)

Address +0 address +1 address See pages

b0 b7 b8 b15

H'0080 0350 TIO5 Counter 10-109

(TIO5CT)

H'0080 0352 (Use inhibited area)

H'0080 0354 TIO5 Reload 1 Register 10-111

(TIO5RL1)

H'0080 0356 TIO5 Reload 0/Measure Register 10-110

(TIO5RL0)

(Use inhibited area)

H'0080 0360 TIO6 Counter 10-109

(TIO6CT)

H'0080 0362 (Use inhibited area)

H'0080 0364 TIO6 Reload 1 Register 10-111

(TIO6RL1)

H'0080 0366 TIO6 Reload 0/Measure Register 10-110

(TIO6RL0)

H'0080 0368 (Use inhibited area)

H'0080 036A TIO6 Control Register TIO7 Control Register 10-107

(TIO6CR) (TIO7CR) 10-108

(Use inhibited area)

H'0080 0370 TIO7 Counter 10-109

(TIO7CT)

H'0080 0372 (Use inhibited area)

H'0080 0374 TIO7 Reload 1 Register 10-111

(TIO7RL1)

H'0080 0376 TIO7 Reload 0/Measure Register 10-110

(TIO7RL0)

(Use inhibited area)

H'0080 0380 TIO8 Counter 10-109

(TIO8CT)

H'0080 0382 (Use inhibited area)

H'0080 0384 TIO8 Reload 1 Register 10-111

(TIO8RL1)

H'0080 0386 TIO8 Reload 0/Measure Register 10-110

(TIO8RL0)

H'0080 0388 (Use inhibited area)

H'0080 038A TIO8 Control Register TIO9 Control Register 10-108

(TIO8CR) (TIO9CR) 10-109

(Use inhibited area)

H'0080 0390 TIO9 Counter 10-109

(TIO9CT)

H'0080 0392 (Use inhibited area)

H'0080 0394 TIO9 Reload 1 Register 10-111

(TIO9RL1)

H'0080 0396 TIO9 Reload 0/Measure Register 10-110

(TIO9RL0)

(Use inhibited area)

H'0080 03BC TIO Enable Protect Register 10-112

(TIOPRO)

H'0080 03BE TIO Count Enable Register 10-113

(TIOCEN)
