10-121

10.4 TIO (Input/Output-Related 16-Bit Timer)

MULTIJUNCTION TIMERS

32180 Group User’s Manual (Rev.1.0)

Count clock

H'FFFF

H'0000

Enabled

(by writing to the enable bit

or by external input)

F/F output

Disabled

(by underflow)

(Unused)

TIO interrupt request

due to underflow

Enable bit

Count down from the

reload 0 register set value

Note: • This diagram does not show detailed timing information.

Reload 0 register

H'A000

Counter

Reload 1 register

Undefined

value

H'(A000-1)

Data inverted by

enable

Data inverted by

underflow

Figure 10.4.12 Typical Operation in TIO Single-shot Output Mode (without Correction Function)
