MULTIJUNCTION TIMERS

10.5 TMS (Input-Related 16-Bit Timer)

32180 Group User’s Manual (Rev.1.0)

Clock bus Input event bus

3 2 1 0 3 2 1 0

clk

TMS 0

ovf

cap3 cap2 cap1 cap0

TCLK3 (P127)

TCLK3S

TIN12S

DMA3

TIN13S

IRQ10

TIN12 (P144)

TIN13 (P145)

TIN14S

TIN14 (P146)

TIN15S

TIN15 (P147)

TIN16S

DMA5

TIN17S

TIN16 (P130)

TIN17 (P131)

TIN18S

TIN18 (P132)

TIN19S

TIN19 (P133)

DMA6

IRQ10

Output event bus

0 1 2 3

IRQ7

: Selector

3 2 1 0 3 2 1 0 0 1 2 3

Measure register 3

Counter

(16-bit)

clk

TMS 1

ovf

cap3 cap2 cap1 cap0

IRQ7

Counter

(16-bit)

Measure register 2

Measure register 1

Measure register 0

Measure register 3

Measure register 2

Measure register 1

Measure register 0

Figure 10.5.1 Block Diagram of TMS (Input-Related 16-Bit Timer)
