10-187

MULTIJUNCTION TIMERS

10.8 TOU (Output-Related 24-Bit Timer)

32180 Group User’s Manual (Rev.1.0)

Figure 10.8.14 Typical Operation in TOU Delayed Single-shot Output Mode (without Correction Function)

H'FF FFFF

H'00 0000

H'10 F000

H'08 A000

H'10 F000

H'10 EFFF

Data inverted

by underflow

Data inverted

by underflow

H'(08 A000-1)

Count clock

Enabled

(by writing to the enable bit

or by external input)

F/F output

Underflow

(first time)

Interrupt request

due to underflow

Enable bit

Note: • This diagram does not show detailed timing information.

Underflow

(second time)

Counter

Reload 1 register

Count down from the

reload register

set value

Undefined

value

Count down from the

counter set value
