Renesas M32R/ECU Series User Manual

11
11-28
A-D Converters
32180 Group User's Manual (Rev.1.0)
11.2 A-D Converter Related Registers
Disconnection detection voltage (without sample-and-hold)
0
200
400
600
800
1000
1200
1400
1600
1800
2000
0 20 40 60 80 100 120
A-D conversion cycle [kHz]
Voltage on disconnected port [mV]
Scan mode: Disconnection detection enabled
Scan mode: Disconnection detection disabled
2900
3100
3300
3500
3700
3900
4100
4300
4500
4700
4900
5100
0 20 40 60 80 100 120
A-D conversion cycle [kHz]
Voltage on disconnected port [mV]
Scan mode: Disconnection detection enabled
Scan mode: Disconnection detection disabled
Disconnection detection voltage (without sample-and-hold)
Figure 11.2.3 A-D Disconnection Detection Assist Data (when Discharge Before Conversion Selected)
Figure 11.2.4 A-D Disconnection Detection Assist Data (when Precharge Before Conversion Selected)
