11-40

A-D Converters

32180 Group User's Manual (Rev.1.0)

11.3 Functional Description of A-D Converters

H'000

H'001

H'002

H'003

H'004

H'005

H'006

→ Output code (hexadecimal)

→ Analog input voltage [mV]

Ideal A-D conversion characteristics

A-D conversion characteristics

with infinite resolution

5 10152025303540455055

H'007

H'008

H'009

H'00A

H'00B

+2 LSB

-2 LSB

Figure 11.3.7 Absolute Accuracy of A-D Converters
