13-42

32180 Group User’s Manual (Rev.1.0)

CAN MODULE

13.2 CAN Module Related Registers

Figure 13.2.10 Block Diagram of the CAN1 Transmit/Receive & Error Interrupt Requests (3/5)

F/F

EOIEN

EOIS

F/F

EPIEN

EPIS

F/F

BEIEN

BEIS

b15

b14

b13

Data bus

CAN bus error occurs

Go to error passive state

Go to bus off state

To the preceding page

(Level)

19-source inputs

CAN1ERIST (H'0080 1414)

CAN1ERIEN (H'0080 1415)

To the remaining 16-source inputs in the next page
