13-49
13
32180 Group User’s Manual (Rev.1.0)
13.2 CAN Module Related Registers
CAN MODULE
CAN0 Global Mask Register Extended ID0 (C0GMSKE0) <Address: H’0080 102A>
CAN0 Local Mask Register A Extended ID0 (C0LMSKAE0) <Address: H’0080 1032>
CAN0 Local Mask Register B Extended ID0 (C0LMSKBE0) <Address: H’0080 103A>
CAN1 Global Mask Register Extended ID0 (C1GMSKE0) <Address: H’0080 142A>
CAN1 Local Mask Register A Extended ID0 (C1LMSKAE0) <Address: H’0080 1432>
CAN1 Local Mask Register B Extended ID0 (C1LMSKBE0) <Address: H’0080 143A>
123456b7b0
EID1MEID0M EID2M EID3M
0000
0
0
0
0
<After reset: H’00>
b Bit Name Function R W
0–3 No function assigned. Fix to "0". 00
4–7 EID0M–EID3M 0: ID not checked R W
(Extended mask ID0–extended mask ID3) 1: ID checked
CAN0 Global Mask Register Extended ID1 (C0GMSKE1) <Address: H’0080 102B>
CAN0 Local Mask Register A Extended ID1 (C0LMSKAE1) <Address: H’0080 1033>
CAN0 Local Mask Register B Extended ID1 (C0LMSKBE1) <Address: H’0080 103B>
CAN1 Global Mask Register Extended ID1 (C1GMSKE1) <Address: H’0080 142B>
CAN1 Local Mask Register A Extended ID1 (C1LMSKAE1) <Address: H’0080 1433>
CAN1 Local Mask Register B Extended ID1 (C1LMSKBE1) <Address: H’0080 143B>
9 1011121314b15b8
EID6MEID5MEID4M EID7M EID8M EID9M EID10M
EID11M
00000000
<After reset: H’00>
b Bit Name Function R W
8–15 EID4M–EID11M 0: ID not checked R W
(Extended mask ID4–extended mask ID11) 1: ID checked
